QJRCY plate suspended conveyor belt magnetic separator
- Category: >>>
- Supplier: Qijin Magnet Co. Ltd.
Share on (1600775000609):
Product Overview
Description
Product Description
Overband Magnetic Separator designed with strong and stable magnetic strength is used for separation of tramp iron from belt conveyed material stream. The advanced design and construction make ideal for use in waste recycling, shredding, mining, wood chips and demolition applications.
Features:
• Applicable for conveyor width from 500mm to 2000mm.
• Deep reaching magnetic circuit design to penetrate heavy product burdens.
• Stainless steel support frame.
• Special sealed bearing block ensure the stable working in harsh environment.
• Easy belt deviation adjustment with screw fasten.
• Magnetic force will not decrease more than 5% within 10 years.
• Deep reaching magnetic circuit design to penetrate heavy product burdens.
• Stainless steel support frame.
• Special sealed bearing block ensure the stable working in harsh environment.
• Easy belt deviation adjustment with screw fasten.
• Magnetic force will not decrease more than 5% within 10 years.
Optional Configuration:
• Electric or Hydraulic Driven Motor
• Ferrite Or Rare Earth Magnet System
• Protection Cover for Belt Running
• Stainless Steel Armed Belt
• Electric or Hydraulic Driven Motor
• Ferrite Or Rare Earth Magnet System
• Protection Cover for Belt Running
• Stainless Steel Armed Belt
Specification
| Type | Beld width (mm) | Belt speed (m/s) | Suspended Height (mm) | Working mode | Motor output (KW) | Weight (KG) |
| QJRCY-L-50 | 500 | <4.5 | 150 | Continuous | 1.1 | 590 |
| QJRCY-L-65 | 650 | 200 | 1.5 | 730 | ||
| QJRCY-L-80 | 800 | 250 | 2.2 | 950 | ||
| QJRCY-L-100 | 1000 | 300 | 3.0 | 1700 | ||
| QJRCY-L-120 | 1200 | 350 | 3.0 | 1950 | ||
| QJRCY-L-140 | 1400 | 4.0 | 2350 | |||
| QJRCY-L-160 | 1600 | 4.0 | 2700 |
