High Quality Custom one stop service pcb board factory pcba assembly Flexible Multilayer pcb printed circuit board in shenzhen
- Category: >>>
- Supplier: Guangzhou,Highleap,Electronic,Co.,Ltd.
Share on:
Product Overview
Description
PCB Capability | ||||||
Item | Rigid PCB | Flexible PCB | Rigi-Flex PCB | |||
Max Layer | 60L | 8L | 36L | |||
Inner Layer Min Trace/Space | 3/3mil | 3/3mil | 3/3mil | |||
Out layer Min Trace/Space | 3/3mil | 3.5/4mil | 3.5/4mil | |||
Inner Layer Max Copper | 6oz | 2oz | 6oz | |||
Out Layer Max Copper | 6oz | 2oz | 3oz | |||
Min Mechanical Drilling | 0.15mm | 0.1mm | 0.15mm | |||
Min Laser Driliing | 0.1mm | 0.1mm | 0.1mm | |||
Max Aspect Ratio(Mechanical Drilling) | 20:01 | 10:01 | 12:01 | |||
Max Aspect Ratio(Laser Drilling) | 1:01 | / | 1:01 | |||
Press Fit Hole Ttolerance | ±0.05mm | ±0.05mm | ±0.05mm | |||
PTH Tolerance | ±0.075mm | ±0.075mm | ±0.075mm | |||
NPTH Tolerance | ±0.05mm | ±0.05mm | ±0.05mm | |||
Countersink Tolerace | ±0.15mm | ±0.15mm | ±0.15mm | |||
Board Thickness | 0.4-8mm | 0.1-0.5mm | ±0.15mm | |||
Board Thickness Tolerance(<1.0mm) | ±0.1mm | ±0.05mm | ±0.1mm | |||
Board Thickness Tolerance(≥1.0mm) | ±10% | / | ±10% | |||
Min Board Size | 10*10mm | 5*10mm | 10*10mm | |||
Max Board Size | 22.5*30 inch | 9*14 inch | 22.5*30 inch | |||
Contour Tolerance | ±0.1mm | ±0.05mm | ±0.1mm | |||
Min BGA | 7 mil | 7 mil | 7 mil | |||
Min SMT | 7*10mil | 7*10mil | 7*10mil | |||
Min solder Mask Clearance | 1.5mil | 3mil | 1.5mil | |||
Min Solder mask Dam | 3mil | 8mil | 3mil | |||
Min Legand Width/Height | 4/23mil | 4/23mil | 4/23mil | |||
Strain Fillet Width | / | 1.5±0.5mm | 1.5±0.5mm | |||
Bow&Twist | 0.003 | / | 0.0005 | |||
About HighLeap Electronic
Advantages of HighLeap Electronic
Our PCB Equipments
Our Certifications
FAQ
Q1:What kind of PCB file format can you accept for production?
Gerber, PROTEL 99SE, PROTEL DXP, CAM350, ODB+(.TGZ)
Q2:Is my PCB files safe when I submit them to you for manufacturing?
We respect customer's copyright and will never manufacture PCB for someone else with your files unless we receive written permission from you, nor we'll share these files with any other 3rd parties.
Q3:What payments do you accept ?
-Wire Transfer(T/T),Western Union,Letter of Credit(L/C)
-Paypal ,Ali Pay,Credit Cart
Q4:How to get the PCBs?
A:For small packages, we will ship the boards to you by DHL,UPS,FedEx,EMS. Door to door service! You will get your PCBs at your home.
B:For heavy goods more than 300kg, we may ship your boards by ship or by air to save freight cost. Of course, if you have your own forwarder, we may contact them for dealing with your shipment.
Q5:What is your minimum order quantity?
Our MOQ is 1 PCS.
Q6: Can we visit your company?
No problem. You are welcome to visit us in Shenzhen. Or the other factory is in GuangDong province.
Q7: How can you ensure the quality of the PCBs?
Our PCBs are 100% test including Flying Probe Test, E-test and AOI.
