Computer controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine
Computer-controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine
Computer-controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine
Computer-controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine
Computer-controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine

Computer controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine

Share on (1600780600540):


Price:$1.00

Quantity:


Product Overview

Description


 Computer-controlled Tensile Performance Helmet Dynamic Belt Retention Test Machine


The test machine suri range:


   With certain initial load appli on the helmet strap system for a certain length of time,then wiht a certain weight weights fall from certain height and make the impact force also applied on the strap system,thereby to judge strap system's resis-tance tensile tensile performance.


Standard:


According to ECE R22.06/EN 1077 /EN 1078/GB24429/CPSC testing standard


1.pneumatic rise device(It's controlled by software,or manul)


2.Initial load:5kg,7kg,15kg


3.Impact weight:4kg,10kg


4.Impact  height:600mm ,750mm


5.High accuracy displacement sensor catch the data


6.HT-6018-A special computer software control rise,down and data calculus


7.Report can save for Word ,Excel,PDF,JPG ect format


8.Connect the printer,can priter the reprot


9.Software surport data save,history data query,data export and print ect


10.Software wiht simplified Chinese,traditional Chinese,English language change function


11.Included a set of professional computer


Picture display:
