Product Overview
Description
Product Description
HiOSO FOWAY Series 100M + 1000M Uplink PoE Switches
FOWAY1305PF 1 100M POE + 1 1000M FX
Overview
HiOSO FOWAY1305PF is a five ports 100M/1000M PoE Ethernet Switch, with 4 10/100M RJ45 PoE ports and 1 1000M FX fiber port uplink, include non-managed type and managed type, managed type supports web management and SNMP management optional..
FOWAY1305PF supports IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards. It can auto discover the power receiving devices which support IEEE802.3af/at standard and supply power to it. To the connected devices which not support PoE, it will auto stop supplying power.
FOWAY1305PF supports to work with IP camera, IP phone, wireless AP and other network devices, and supply power to these devices, supports to transmit HD video flow; applies to Security system, electronic power system and traffic system requirements.
Character
l Support 4 100M PoE ports and 1 1000M FX port
l Each PoE port supports to auto discovery the standard power receiving devices
l Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
l Support each port full rate, full-duplex non-blocking forwarding
l 8K MAC learning, 1Mbit storage and forward cache space, 7.6G back bandwidth
l Optional to support CLI,WEB or SNMP
l Managed version support VLAN, STP/RSTP/MSTP, Trunk port aggregation, IGMP, port Mirroring, port isolation, broadcast storm control, loop detection, bandwidth allocation, QinQ, etc; SNMP Support LLDP, DHCP, PPPoE, ACL
l Support to provide wall-mounted hanger better for installation if need, external power design and metal casing better for heat dissipating
Technical Specification
Parameter | Specification |
Standard | IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3ab 1000Base-T,IEEE802.3z 1000Base-SX/LX Gigabit Ethernet,IEEE802.1d Spanning Tree Protocol,IEEE802.1w Rapid STP,IEEE802.1s Multiple STP,IEEE802.1q Vlan,IEEE802.1p QoS,IEEE802.3ad Trunk,IEEE802.3X Flow Control |
PoE | Power supply ports: 4 ports Standard and power consumption: IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discovery power receiving devices and auto power supply/ cutting |
Wavelength | 850nm/1310nm/1490nm/1550nm |
Distance | 1000M fiber multi-mode: 220m (fiber 62.5/125μm)/ 550m (fiber 50/125μm) Single-mode:10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80/100/120Km |
Port | 4 100M RJ45 ports (PoE optional): 10/100Mbps 1 1000M FX uplink port:SC |
MAC | 8K |
Buffer memory space | 1Mbit |
Bit error rate | <1/1000000000 |
MTBF | 100000 hours |
Power | DC48V |
Power consumption | The whole device 4.8W, PoE power supplying maximum 120W |
Working temperature | -10~60℃ |
Storage temperature | -40~80℃ |
Humidity | 5%~90% non-condensing |
Dimension | 28mm (H)×120mm(W)×106mm (D) |
Order information
No | Product code | NMS | Ports | PoE ports |
1 | FOWAY1305PF-8AF | No | 4 100M TP + 1 1000M FX | 4 PoE ports IEEE802.3af 62W |
2 | FOWAY1305PF | No | 4 100M TP + 1 1000M FX | 4 PoE ports IEEE802.3af 62W |
3 | FOWAY1305PF-120W | No | 4 100M TP + 1 1000M FX | 4 PoE ports IEEE802.3af/at 120W |
4 | FOWAY1305PFM-8AF | YES | 4 100M TP + 1 1000M FX | 4 PoE ports IEEE802.3af 62W |
5 | FOWAY1305PFM | YES | 4 100M TP + 1 1000M FX | 8 PoE ports IEEE802.3af/at 62W |
6 | FOWAY1305PFM-120W | YES | 4 100M TP + 1 1000M FX | 4 PoE ports IEEE802.3af/at 120W |
