Buy industrial heavy duty paper shredder machine for sale
- Category: >>>
- Supplier: suzhou ounaisi machinery manufacturing CO. LTD
Share on (1600787232108):
Product Overview
Description
Product Description
Parameter table
Model number | Motor power | Number of blades | Length, width and height | yield |
NS-D600 | 30kw | 29 | 2200X1200X2300 | 300-500kg/H |
NS-D800 | 37kw | 46 | 2700X1450X2300 | 500-800kg/H |
NS-D1000 | 55kw | 58 | 2700X1650X2500 | 800-1000KG/h |
NS-D1200 | 75KW | 82 | 3600X2200X2300 | 900-1100KG/h |
NS-D1300 | 75KW | 84 | 2700X1650X2500 | 1000-1200KG/h |
Product Description
General introduction
Plastic crusher is used for recycling waste materials in plastic industry. It is made up with hopper, cutting chamber, knife seat, cutting tool, motor, base and controlling cabinet. There is safety interlock between the feeding hopper and the chamber. The hopper is made of double-layer hollow steel board for reducing the noise. Protective curtain is also matched in with the feeding mouth to prevent the crushed materials out. The electrical system has grounding, voltage loss and overload protection with all the controlling device installed in the sealed box. Whole machine controlled by PLC, it will be set before delivery, non-professional man must not revise the PLC program.
Application
1. All kinds of hollow containers: plastic beverage cans, plastic barrels, drums, packing box, packing barrel
2. Waste appliances: TV, washing machine, refrigerator shell, printer, keyboard, waster Microwave oven,waster computer,waster
mouse,Circuit board.
3. Pipe: large pipe, pipe fittings, PE pipe,PVC tube.
4. Waste template: wooden pallets, plastic pallets, forklift pallets,Used furniture.
5. Scrap tires:car tires, truck tires, engineering tires.
6. Scrap metal: car shell, aluminum alloy, scrap aluminum castings, engine shell
7. Garbage:Food waste,animal carcass, medical waste, garden garbage,Fruit trash,Vegetable trash,glass.
8.Rubber head material, papper mill rope.
2. Waste appliances: TV, washing machine, refrigerator shell, printer, keyboard, waster Microwave oven,waster computer,waster
mouse,Circuit board.
3. Pipe: large pipe, pipe fittings, PE pipe,PVC tube.
4. Waste template: wooden pallets, plastic pallets, forklift pallets,Used furniture.
5. Scrap tires:car tires, truck tires, engineering tires.
6. Scrap metal: car shell, aluminum alloy, scrap aluminum castings, engine shell
7. Garbage:Food waste,animal carcass, medical waste, garden garbage,Fruit trash,Vegetable trash,glass.
8.Rubber head material, papper mill rope.
1.Heavy-duty construction and efficient performance are determined by the precisely processed combined frame made of extra-thick
plates
2. Wide angle, hexagon prism of power slewing axis; large hopper with big caliber for feeding large material
3. It adopts PLC control system, automatic overload protection and auto reverse switch
4. The low rotation speed results in a particularly quiet shredding process with low levels of dust generation
5. It can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc
plates
2. Wide angle, hexagon prism of power slewing axis; large hopper with big caliber for feeding large material
3. It adopts PLC control system, automatic overload protection and auto reverse switch
4. The low rotation speed results in a particularly quiet shredding process with low levels of dust generation
5. It can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc
Product Detail
Belt Conveyor
● The plastic waste is conveyed into the shredder through the belt feeding device;
● The device adopts ABB/Schneider frequency
converter for frequency control.
● The conveying speed of the belt feeding device is linked with the fullness of the shredder, and
the speed of the conveyor belt is automatically adjusted according to the current of the shredder.
the speed of the conveyor belt is automatically adjusted according to the current of the shredder.
Metal Detector
● Optional Ferrous Metal Permanent Magnetic Belt or metal detector can prevent metal specials from entering the shredder and effectively protect the blades of the shredder.
Hopper
● Special designed hopper to avoid material flying out. The machine is fitted with a large filling hopper and can be loaded by
conveyor belt, fork lift, crane or wheel-loader. This funnel can be adapted to suit individual requirements and guarantees a
continuous and economical supply of material.
conveyor belt, fork lift, crane or wheel-loader. This funnel can be adapted to suit individual requirements and guarantees a
continuous and economical supply of material.
Hydraulic Ram
● The hydraulically operated pusher feeds the material towards the cutter automatically by load-related controls. The hydraulic
system is equipped with overflow valves and volumetric flow controls, which can be both set according to the demands of the input
materials.
system is equipped with overflow valves and volumetric flow controls, which can be both set according to the demands of the input
materials.
Rotor
● The rotor is made of seamless steel pips with the diameter of 560mm and operates at a speed of 72 rpm. The concave ground,
aggressive and 4-way rotating knives are mounted in the grooves of the rotor. This enables a reduction of the cutting gap between
the counter knives and the rotor and guarantees a high flow rate, low power consumption and maximum output of ground material.
aggressive and 4-way rotating knives are mounted in the grooves of the rotor. This enables a reduction of the cutting gap between
the counter knives and the rotor and guarantees a high flow rate, low power consumption and maximum output of ground material.
Knife Blades
● Knife Blades Material: DC53 Higher hardness (62-64 HRc) than D2/SKD11 after heat treatment.
● Twice the toughness of D2/SKD11
with superior wear resistance.
with superior wear resistance.
● Substantially higher fatigue strength compared to D2/SKD11.
Screen
● The screen mounted beneath the rotor determines the size of the required flakes. The screen is also easily accessible by a
separate flap and can be changed easily. The screen can be opened or closed hydraulically.
separate flap and can be changed easily. The screen can be opened or closed hydraulically.
Shredder Chamber
● The shredder chamber is welded with 30mm ultra-high hardness steel plate, which is wear-resistant, corrosion-resistant,
low-noise, and has a longer service life.
low-noise, and has a longer service life.
Motor
● Adopt imported brand motor WEG, low energy consumption, low noise, long service life.
Electronic Control
● The whole model adopts frequency conversion control and conforms to international standards such as CE/CSA.
Product Images
About Us
Company Profile
The company has a high quality, efficient marketing and technical service team and a large number of experienced professional and technical personnel and senior engineers. To provide customers with more effective, more professional, more perfect technical support and after-sales service. With the development of The Times, the company always pays attention to the field of plastic new products and new technology and grasp and control, keep pace with The Times, always with advanced concepts and mature and perfect technology applied to project development, customer-centric, comprehensive consideration of technological advancement and economic rationality, strive for the maximum customer satisfaction is always our goal, rapid response, Correct direction and efficient on-site processing is our service tenet.
Suzhou Onez Machinery Manufacturing Co., Ltd. will make unremitting efforts to achieve self-transcendence in technology and service, but also to create and provide excellent products with real value to customers side by side with our customers to welcome a better future. Suzhou Onez Machinery Manufacturing Co., Ltd. integrity, strength and product quality has been recognized by the industry. Welcome friends from all walks of life to visit Suzhou Oanes Machinery Manufacturing Co., LTD. Visit, guidance and business negotiation.
Suzhou Onez Machinery Manufacturing Co., Ltd. is a national designated enterprise specializing in the research and development, production and sales of plastic machinery. The company continues to introduce domestic and foreign advanced technology, pay attention to technological reform, and constantly develop new products. The main products are plastic twin screw extruder, series of single screw extruder, metal and non-metal plastic composite pipe, composite plate production line; Complete production line of plastic profile, sheet and sheet; Plastic recycling and cleaning production line and a variety of auxiliary equipment.
The company has a high quality, efficient marketing and technical service team and a large number of experienced professional and technical personnel and senior engineers. To provide customers with more effective, more professional, more perfect technical support and after-sales service. With the development of The Times, the company always pays attention to the field of plastic new products and new technology and grasp and control, keep pace with The Times, always with advanced concepts and mature and perfect technology applied to project development, customer-centric, comprehensive consideration of technological advancement and economic rationality, strive for the maximum customer satisfaction is always our goal, rapid response, Correct direction and efficient on-site processing is our service tenet.
Suzhou Onez Machinery Manufacturing Co., Ltd. will make unremitting efforts to achieve self-transcendence in technology and service, but also to create and provide excellent products with real value to customers side by side with our customers to welcome a better future. Suzhou Onez Machinery Manufacturing Co., Ltd. integrity, strength and product quality has been recognized by the industry. Welcome friends from all walks of life to visit Suzhou Oanes Machinery Manufacturing Co., LTD. Visit, guidance and business negotiation.
Company Certificate
Factory strength
Exhibition
All staff
Group photo of foreign customers
FAQ
1. Is your company transactional or industrial?
Suzhou Nesi Machinery Manufacturing Co., Ltd. is an industrial manufacturing enterprise.
If you are interested in our products, we can meet your requirements, you can come to our company for a visit.
2. Do you make all your own products or do you buy compacted ones from others?
● We have an independent technical team, focusing on manufacturing machines, all products are manufactured by our technical team.
● All machines are made of high quality. We are very strict with the selection of materials. All materials coming to our factory must pass testing.
3. Do you have any other services for your products?
We have rich experience in developing projects and specifications for customers, and have a fixed service system.
4. How do you quote to the customer?
The price depends on quality and performance, but the customer must be satisfied first.
5.Do you have after-sale service?
● When all equipment is completed, we will connect all machines and run the full production line for at least 12 hours to ensure the stable operation of the customer's plant.
● After commissioning, we will pack the equipment in standard export packaging for shipment.
● After the agreement with the customer, our engineers will go to the customer's factory for installation and training.
● Engineers, sales managers and after-sales service managers form an online and offline after-sales team to track customer projects throughout the process.
Suzhou Nesi Machinery Manufacturing Co., Ltd. is an industrial manufacturing enterprise.
If you are interested in our products, we can meet your requirements, you can come to our company for a visit.
2. Do you make all your own products or do you buy compacted ones from others?
● We have an independent technical team, focusing on manufacturing machines, all products are manufactured by our technical team.
● All machines are made of high quality. We are very strict with the selection of materials. All materials coming to our factory must pass testing.
3. Do you have any other services for your products?
We have rich experience in developing projects and specifications for customers, and have a fixed service system.
4. How do you quote to the customer?
The price depends on quality and performance, but the customer must be satisfied first.
5.Do you have after-sale service?
● When all equipment is completed, we will connect all machines and run the full production line for at least 12 hours to ensure the stable operation of the customer's plant.
● After commissioning, we will pack the equipment in standard export packaging for shipment.
● After the agreement with the customer, our engineers will go to the customer's factory for installation and training.
● Engineers, sales managers and after-sales service managers form an online and offline after-sales team to track customer projects throughout the process.
