Huasan (H3C)R4900G3 server Host 2U rack 3204 1.9GHz Virtualized Big Data Data Warehouse
- Category: Servers >>>
- Supplier: Beijing,Huaxin,Hengyuan,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Specification
Processor | Support up to 2 Intel®Xeon®Scalable family processor or Lanqi Jin catch®Processor series, single up to 28 cores, maximum power 205W |
Chipset | Intel®C622 |
Memory | Support up to 24 DDR4 memory slots, support up to 2933MT/s, support RDIMM or LRDIMM, support up to 12 Intel with a maximum capacity of 3TB per processor®Aoteng™Data Center Class Persistent Memory (DCPMM) |
Storage Controller | Standard onboard array controller supporting SATA RAID 0/1/10/5 Optional array card dedicated slot-based HBA card supporting SATA/SAS RAID 0/1/10 Optional array card based on array card proprietary slot, supports RAID0/1/10/5/6/50/60/1E Optional standard PCIe slot-based HBA and array cards |
FBWC | Optional support for up to 8GB cache with super capacitor protection |
Storage | Support for up to 20 x 3.5 "HDD, 4 x 2.5" HDD (12 front, 4 internal expansion, 8 rear expansion) Support for up to 37 2.5 "HDDs, 3 3.5" HDDs (25 front, 8 internal expansion, 7 rear expansion) Supports SAS/SATA HDD/SSD HDD, supports front/internal NVMe HDD, supports up to 32 NVMe HDD slots 1 Support for SATA M.2 option |
Network | Onboard 1 1Gbps management network port Optional 4 × 1GE electrical port or 2 × 10GE electrical port/optical port expansion through mLOM Optional standard PCIe slot-based network adapter |
Expansion Slot | Up to 10 PCIe 3.0 available slots (including 1 array card dedicated slot and 1 NIC dedicated slot) |
Interface | Optional front VGA, standard rear VGA and serial port, 5 USB 3.0(1 front, 2 rear, 2 internal), optional 1 USB 2.0 and 2 Micro SD card kits |
GPU Support | Supports up to 3 double-wide GPU cards or 8 single-wide GPU cards |
Optical Drive | Support external optical drive, some models support built-in optical drive |
Management | HDM agentless management tool (with independent management port) and H3C FIST management software, supporting 16M local video memory |
Security | Support chassis intrusion detection, TCM/TPM security module, optional PCIe protection module, providing protection functions such as firewall, IPS, anti-virus and QoS |
Power and heat dissipation | Optional Platinum Class 550W / 800W / 850W / 1200W / 1600W 1 1 redundant power supply, Optional Titanium Class 1 1 redundant power supply Optional 800W Negative 48V / 336V DC Power Module, Supports 1 1 Redundancy Supports hot-swappable redundant fans |
Certification | Support CCC,CECP,SEPA, CE, CB and other certification |
Working temperature | 5 ℃ - 50 ℃ (operating temperature support is affected by different configurations, please refer to the detailed product technical document description for details) |
Shape/Chassis Dimensions | 2U Chassis 87.5mm (height) * 445.4mm (width) * 748mm (depth) (without security panel) 87.5mm (height) * 445.4mm (width) * 771mm (depth) (including safety panel) |
Warranty | 3 years 5 × 9, next 1 weekday response (NBD) |
Brand | Xinhua 3 (H3C) |
item | value |
Products Status | Stock |
Type | Rack |
Processor Main Frequency | 2.2GHz |
Processor Type | Intel |
Brand Name | Xinhua 3 (H3C) |
Model Number | R4900G3 Server |
Place of Origin | China |
Beijing | |
Product Name | Server Motherboard |
Form Factor | 2U Rackmount |
Processor | IntelXeonScalable Processor |
Power Supply | 800W |
Hard Drive | 2.5/3.5 SAS/SATA/SSD/NVME |
Memory type | DDR4-ECC |
Memory | 32GB |
RAID Controller | H330 |
Warranty | 3 Years |
Brand | Xinhua 3 (H3C) |
Packing & Delivery
Original packaging
Company Profile
Beijing Huaxin Hengyuan Science and Technology Co., Ltd. is committed to the construction of China's information industry. We are a provider of computer infrastructure sales and comprehensive services for customers. We have a professional team that responds quickly and provides customers with professional technical solutions. The product categories are rich: servers, storage, switches, workstations, video conferencing, etc. Sufficient supply of goods, high-quality products, help partners to take the lead in the fierce market competition. Establish long-term cooperative relationship, create rich value and win-win cooperation.
