Heavy Duty Plywood Wide Belt Sanding Sander Machine
- Category: >>>
- Supplier: Shandong STX Machinery Trade Co. Ltd.
Share on (1600788264135):
Product Overview
Description
Heavy Duty Plywood Wide Belt Sanding Machine
Product Description
1.Heavy-duty sanding, full rigidity, stable and reliable
2.The production efficiency is 80% higher than that of the same level model
3. The automatic edge patrol technology reduces the number of shutdowns and saves 60% of useless work time
4.High linear speed sanding, double the smoothness of sanding under the same working conditions, and increase the smoothness by 30%
2.The production efficiency is 80% higher than that of the same level model
3. The automatic edge patrol technology reduces the number of shutdowns and saves 60% of useless work time
4.High linear speed sanding, double the smoothness of sanding under the same working conditions, and increase the smoothness by 30%
Specification
Model | BSG2213X | BSG2113X |
Max. Working Width (mm) | 1300 | 1300 |
Min. Working Length (mm) | 856 | 856 |
Working Thickness (mm) | 3-100 | 3-100 |
Roller Diameter (mm) | φ400/φ400 | φ400 |
Roller hardness (sh) | steel/steel | steel |
Air pressure (Mpa) | 0.6 | 0.6 |
Belt size (mm) | 1350 x 2800 | 1350 x 2800 |
Feeding speed (m/min) | 10-65 | 10-65 |
Total power | 143 | 143 |
Machine size (mm) | 3150 x 3170 x 2450 | 3185 x 2315 x 2450 |
Support height (mm) | 920 x 1020 | 920 x 1020 |
Machine Weight (kg) | 10800 | 7400 |
Double Steel Roller Structure
The sanding amount of a plate can reach 1mm, the design size of the sand roller is φ400mm, and the wall thickness is 45mm. The tension roller wall thickness is 16mm. And the overall heat treatment of the emery roller and the tension roller to fully eliminate the internal stress
Turbine Transmission
The machine has developed a turbine transmission, four-station synchronous lifting system, no gap synchronous operation, and is the industry's first creation. Eliminated the chain transmission method for more than 20 years. Improve the processing accuracy of the plate, reaching + 0.04mm
The conveying bed is designed as a assembled structure based on the high-quality Q235 material of the thickness of 6 = 25 mm. Solved the original welding, the thickness of the thickness of the rigidity has increased by 57 times the wear resistance after
the original 45 # steel heat treatment.
the original 45 # steel heat treatment.
The equipment is run in standard working hours, and there is no need to repair the equipment in 5 years.
The conveying base platform has a negative pressure vacuum device, which is effective to take a wood shot in the conveyor belt to ensure that the reference platform accuracy, the inclined beam sanding machine has a conveyor belt running problem, the machine design four roller synchronization
High Sanding power
First sanding unit power 75KW
Second sanding unit power 55kw
Top quality components
FAQ
1. who are we?
We are based in Shandong, China, start from 2018,sell to Southeast Asia(35.00%),Africa(15.00%),Mid East(15.00%),Oceania(15.00%),North America(10.00%),Eastern Asia(10.00%),South America(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Automatic four side moulder production line,Automatic wood sanding machine,Automatic wood floor production line,Optimizing cross cut saw,Single/multi rip saw machine
4. why should you buy from us not from other suppliers?
1.Provide customized woodworking technical solutions
2.Provide high quality and competative price machines
3.Owned powerful design,R&D,machining capability.
4.High efficiency pre-sals and after sales service.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,German,Arabic,French,Russian,Korean
We are based in Shandong, China, start from 2018,sell to Southeast Asia(35.00%),Africa(15.00%),Mid East(15.00%),Oceania(15.00%),North America(10.00%),Eastern Asia(10.00%),South America(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Automatic four side moulder production line,Automatic wood sanding machine,Automatic wood floor production line,Optimizing cross cut saw,Single/multi rip saw machine
4. why should you buy from us not from other suppliers?
1.Provide customized woodworking technical solutions
2.Provide high quality and competative price machines
3.Owned powerful design,R&D,machining capability.
4.High efficiency pre-sals and after sales service.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,German,Arabic,French,Russian,Korean
