Dell PowerEdge R940xa 4U Rack Server
- Category: >>>
- Supplier: Beijing Meicheng Boshi Technology Co. Ltd.
Share on (1600788950376):
Product Overview
Description
Product Description
Product Description
Dell POWEREDGE R940xa
Rapidly transform data insights into business outcomes with the PowerEdge R940xa. The R940xa accelerates applications with
powerful four-socket performance in a scalable 4U design.
powerful four-socket performance in a scalable 4U design.
The PowerEdge R940xa drives GPU database acceleration to deliver real-time decisions for compute-intensive applications. By combining four CPUs with four GPUs, the R940xa delivers consistent high performance for demanding applications
Specification
Specification
Processor | Up to four 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores each |
Memory | 48 DDR4 DIMM slots, Supports RDIMM /LRDIMM, up to 2933MT/s, 6TB max Up to 12 NVDIMM, 384GB Max Up to 24 Intel® Optane™ DC persistent memory DCPMM, max 12.28TB, (15.36TB max with DCPMM and LRDIMM) Supports registered ECC DDR4 DIMMs only |
Storage controllers | Internal Controllers: PERC H730P, H740P, H330 Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 240GB or 480GB External PERC (RAID): H840 12Gbps SAS HBAs (non-RAID): External-12Gbps SAS HBA (non-RAID). Internal-HBA330 (non-RAID) |
Drive bays | Front drive bays: Up to 8x 2.5” SAS SATA (HDD/SSD) max 61.44TB, or up 24 x 2.5” SAS/SATA (HDD/SSD) max 184.32TB, or up to 32 SAS/SATA (HDD/SSD) with up to 4 NVME PCIe SSD max 245.76TB |
Power supplies | Gold 1100W -48VDC Platinum: 1100W, 1100W 240VDC1 1600W, 2000W, 2400W Hot plug power supplies with full redundancy option 6 hot plugs fans with N +1 redundancy |
Dimensions | Height: 174.3 mm (6.87”) Width: 441.16 mm (17.37”) Depth: 835.9mm (32.9”) Weight: 56.0kg (123.5lbs.) *Dimensions do not include bezel |
Embedded management | iDRAC9 iDRAC Direct |
OpenManage™ Software | OpenManage Enterprise OpenManage Essentials |
I/O & Ports | Network Daughter Card Options 4 x 1GbE, 4 x 10GbE, 2 x 10GbE+2 x 1GbE, or 2 x 25GbE Front ports: 1 x Dedicated iDRAC Direct Micro-USB, 2 x USB 2.0, 1 x VGA. (Optional 1 x USB 3.0 only offered on the 8-drive configuration) Rear ports: 1 x Dedicated iDRAC port, 1 x Serial, 2 x USB 3.0, 1 x VGA Internal port: 1 x USB 3.0 Video card: 2 x VGA PCIe: Up to 12 x Gen3 slots, (6x16 slots or 2x16 + 10x8 slots) |
Supported operating systems | Canonical® Ubuntu® LTS Citrix® Hypervisor Oracle® Linux Microsoft Windows Server® LTSC with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi For specifications and interoperability details |
