Flexible PCB Fpcb for LED Strip Factory
US $28.00-$30.00
Гибкая печатная плата односторонняя гибкая печатная плата PCB pcba сервис FPC поставщик
- Category: FPC >>>
- Supplier: Shenzhen,Wanfeng,Technology,Co.,Ltd.
Share on:
Product Overview
Description
FPC PRODUCTION CAPABILITY | ||||
Item | Content | Regular Capability | Special | |
1 | Layer | 1-6L | Above 8L | |
2 | Max.Array Size | 500*600mm | 250*1500mm | |
3 | Min.board Size | 1-*1mm | ||
4 | Max.board thickness | 0.23mm | 0.4mm | |
5 | Min.board thickness | 0.075mm | 0.065mm | |
6 | (0.075mm≤T Tolerance±0.03mm | V | 575 | |
7 | (0.035mm≤T Tolerance±0.05mm | ℃ | 130 | |
8 | (0.6mm≤T Tolerance±0.1mm | %(50-260℃) | 0.5 | |
9 | Max Drill bit Diameter | 6.5mm | ||
10 | Min Drill bit Diameter | 0.20mm | 0.15mm | |
11 | Routing tolerance | ±0.2mm | ±0.15mm | |
12 | Min Base Copper | 1/3 OZ | 1/4 OZ | |
13 | Max Base Copper | 2 OZ | 4 OZ | |
14 | Min Coverlay Thickness | 1mil(PI0.5mil Adhesive 0.5mil) | ||
15 | Max Coverlay Thickness | 2mil(PI1mil Adhesive 1mil) | ||
16 | Tolerance of holes diameter(PTH) | ±0.05mm | ||
17 | Tolerance of holes diameter(NPTH) | ±0.025mm | ||
18 | Hole Position Deviation(hole to hole compared with the CAD data) | ±0.05mm | ||
19 | Hole Position Deviation(copper foil to hole compared with the CAD data) | ±0.07mm | ||
20 | PTH wall copper thickness | 12-18um | ||
21 | Minimum Trace Width/Space | 1/3OZ Cu 1L 50/60um 1/2OZ 2L 70/80um 1OZ Cu 1L 70/80um 1OZ Cu 2L 80/90um | ||
22 | Min distance copper foil to the edge | ±0.10mm | ±0.07mm | |
23 | Offset tolerance of silk character | ±0.3mm | ±0.2mm | |
24 | Soldermask printing offset tolerance | Photo sensitive:±0.1mm(±4mil) Printed backing:±0.3mm(±8mil) | ±0.075mm ±0.2mm | |
25 | Soldermask thickness | Photo sensitive:0.007-0.02mm(0.3-0.8mil) Printed backing:0.01-0.025mm(0.4-1mil) | ||
26 | Protective film alignment accuracy(joint offset tolerance) | ±0.15mm | ±0.10mm | |
27 | Min protective film lamination spilled glue amount | 0.5mil Adhesive≤0.1mm(4mil) 1mil Adhesive≤0.15mm(6mil) | ||
28 | Tin thickness(Max),(Min)/Tolerance | (0.2mil)-(2.0mil)±0.30mm | ||
29 | Gold plating, Ni thickness(Gold finger or other parts) | 1-6 u inch | Min 30 u inch Max 280 u inch | |
30 | Gold plating, Au thickness(Gold finger or other parts) | 1-6u inch | 1-10 u inch | |
31 | ENIG Ni/Au thickness(Gold finger or other parts) | Ni:30-150u inch Au:±1u inch | 4 u inch | |
32 | (OSP) | 0.2-0.8um | ||
33 | Die Punching Min hole/tolerance | Min:0.5mm/±0.05mm | +0.06/-0mm | |
34 | Alignment tolerance of manual joint operation | ±0.30mm | ±0.2 | |
35 | Alignment tolerance of fixture joint operation | ±0.15mm | ||
TEST QUALITY CONTROL | Aluminum Production Capability | |||
Item | Testing Content | Condition | ||
1 | Voltage of E-test | 250±25V | ||
2 | Short circuit impedance | ≥100Ω | ||
3 | Open-circuit impedance | ≥100Ω | ||
4 | Solderability testing | 245±5℃,5Sec | ||
5 | Heat stress testing | 288±5℃,10Sec | ||
6 | Thermal resistance | 94V-0 | ||
7 | Min tolerance for impedance control | ±10% | ||
POE PCB PCBA Assembly
POE has the capability to manufacture PCB ranging from basic single sided PCB boards up to 40 layer Multi-layer PCB and provide one stop turnkey PCB services, including PCB manufacturing, PCB assembling, PCBA components sourcing and PCBA function testing.
Since 1996, POE has established itself as a premier provider of PCB Fabrication, PCB Assembly, and Part Procurement services. Over the years, our customers have relied on us to deliver their time sensitive jobs with the highest level of quality. We have
capability to produce FR4 PCBs, Aluminum PCBs, HDI PCBs, Multilayer PCBs (up to 40 layers), Gold Finger PCBs and Rogers PCBs. POE has been dedicated to the manufacture and supply of high quality printed circuit boards which are widely used in many industries such as communications, medical equipment, industrial, aerospace, computers, automotive, power and instrumental industries. Whether your need is for small volume prototypes, medium or high-volume production, POE is driven to always delivery high quality goods and services, on time, and on budget.
capability to produce FR4 PCBs, Aluminum PCBs, HDI PCBs, Multilayer PCBs (up to 40 layers), Gold Finger PCBs and Rogers PCBs. POE has been dedicated to the manufacture and supply of high quality printed circuit boards which are widely used in many industries such as communications, medical equipment, industrial, aerospace, computers, automotive, power and instrumental industries. Whether your need is for small volume prototypes, medium or high-volume production, POE is driven to always delivery high quality goods and services, on time, and on budget.
VR
Product packaging
Our company is not only trying to give customers a good product but also pay attention to offering a complete and safe package. And here we prepare some personalized services for all the orders.
Common packaging:
PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box
Shipping:
1. Confirming your shipping address is correct before delivery
2. Orders processed timely after the payment verification
3. Professional package. No worry about goods breakage.
4. Service transit time is upon different carriers, may vary particularly during holiday.
Common packaging:
PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box
Shipping:
1. Confirming your shipping address is correct before delivery
2. Orders processed timely after the payment verification
3. Professional package. No worry about goods breakage.
4. Service transit time is upon different carriers, may vary particularly during holiday.
FAQ
Q: What is needed for PCB/PCBA quotation?
A: For Bare PCB project, please provide Quantity, Gerber file and specifications like material, surface finish treatment, copper thickness, board thickness, solder mask color and silkscreen color and other special specs.
For PCBA project, please provide above information as well, and BOM list, pick and place file.
If you need turnkey service include programming and functional testing etc, kindly contact us for more details.
Q: Are my files safe?
A: Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties. We are willing to sign an NDA effect by customer side local law and promising to keep customers data in high confidential level.
Q: What’s your minimum of quantity (MOQ)?
A: There is no MOQ in POE (PCBA Shenzhen). We are able to handle small as well as large volume production with flexibility.
Q: How to calculate the shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
Q: What other service do you have?
A: We mainly focus on PCB + Assembly + Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.
Q: Can we inspect quality during production?
A: Yes, we are open and transparent on each production process. We Welcome you visit our factory to inspect our production process.
Q: What is your testing policy and how do you control the quality?
A: Regarding to PCB samples, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by Electrical fixture which is faster. As to PCBA production, there are automated optical inspection (AOI) for each batch, X-ray inspection for BGA parts, first article inspection (FAI) before mass production.
