Hitop Battery Reach Forklift Stand up Seated Warehouse Electric Stacker Forklift 1.5 ton 2 ton 3 ton 2.5ton Electric Reach Truck
- Category: >>>
- Supplier: Hitop Machinery Co. Ltd.
Share on (1600792869092):
Product Overview
Description
Products Description
Hitop Battery Reach Forklift Stand-up Seated Warehouse Electric Stacker Forklift 1.5 ton 2 ton 3 ton 2.5ton Electric Reach Truck
HITOP CDD Series Electric Stand On Type Reach Truck
Main Features:
1.Curtis controller, more safe and stable
2.Free maintenance AC drive system and full AC system
3.Semi-enclosed cab and fork positioner
4.Reasonable layout, low center gravity, small size
5.Imported proportional valve, handle and display
6.Electromagnetic Braking System
7.Side pulled battery,free battery changing trollry
8.Imported Germany brand transmission
1.Curtis controller, more safe and stable
2.Free maintenance AC drive system and full AC system
3.Semi-enclosed cab and fork positioner
4.Reasonable layout, low center gravity, small size
5.Imported proportional valve, handle and display
6.Electromagnetic Braking System
7.Side pulled battery,free battery changing trollry
8.Imported Germany brand transmission
Product Details
Electric Reach Truck Specification
Brand | HITOP | |||
Model | CDD | |||
Power type | Battery | |||
Driving type | Stand | |||
Load capacity | kg | 2000 | ||
Load center | mm | 500 | ||
Net weight(with battery) | kg | 3100 | ||
Wheel | ||||
Tyre type | PU | |||
Driving wheel | mm | Ø343*135 | ||
Front universal wheel | mm | Ø267*50（double） | ||
Front steering wheel | mm | Ø267*114 | ||
Dimension | ||||
Lifting height | mm | 3000-12000mm | ||
Overall length | mm | 2480 | ||
Overall width | mm | 1350 | ||
Overall height(mast lowered) | mm | 2100 | ||
Minimum ground clearance | mm | 80 | ||
Max. overall height(mast extended) | mm | 3985 | ||
Fork size | mm | 1070*120*40 | ||
Fork adjustable range | mm | 300-820 | ||
Width of minimun aisle for side traveling | mm | 3100（1000*1000mm pallet） | ||
Turning radius | mm | 1900 | ||
Overhead guard height | mm | 2190 | ||
Max. travel speed, laden/unladed | Km/h | 7.0/8.0 | ||
Max. Side travel speed, laden/unladed | Km/h | 5.0/6.0 | ||
Lifting speed, laden/unladed | mm/s | 120/270 | ||
Direct travel gradeability, laden/unladed (S2-5min) | % | ≤8 | ||
Side travel gradeability, laden/unladed (S2-5min) | % | ≤5 | ||
Brake type | Electromagnetic | |||
Electric-engine | ||||
Drivie motor | kw | 6.5 | ||
Lift motor | kw | 8.0 | ||
Battery voltage/capacity | V/Ah | 48/400 | ||
Charger | V/Ah | 48 / 50 | ||
Electric Reach Truck Features
Human comfort operation
● Large and strong chassis.
● Spacious and comfortable compartment with adjustable seat.
● Use dual controllers to realize stepless speed regulation of both lifting and traveling speed.
● Spacious and comfortable compartment with adjustable seat.
● Use dual controllers to realize stepless speed regulation of both lifting and traveling speed.
STABILITY
● Have limited travel speed safety device on the mast.
● Fully hydraulic steering system makes turns easy and flexible.
● Adopt hydraulic brake for two front wheels and electric brake for electric brake for driving motor.
● Integrated design of driving and steering system without chain transmission.
● Fully hydraulic steering system makes turns easy and flexible.
● Adopt hydraulic brake for two front wheels and electric brake for electric brake for driving motor.
● Integrated design of driving and steering system without chain transmission.
EASY MAINTENANCE
● Have limited travel speed safety device on the mast.
● Fully hydraulic steering system makes turns easy and flexible.
● Adopt hydraulic brake for two front wheels and electric brake for electric brake for driving motor.
● Integrated design of driving and steering system without chain transmission.
● Fully hydraulic steering system makes turns easy and flexible.
● Adopt hydraulic brake for two front wheels and electric brake for electric brake for driving motor.
● Integrated design of driving and steering system without chain transmission.
Optional Configurations
Multifunctional Attachments
Certifications
Company Profile
Hitop Machinery Co., Ltd. is a professional forklift manufacturer and supplier, with production base covering more than 30,000 square meters. We are an ISO9001/SGS certified enterprise. Our factory has advanced parts processing centers, hydraulic press machines, bending machines, shearing machines, welding robots, etc., as well as painting lines, final assembly lines, and performance test beds for the entire machine. We have a strict management of the quality of raw materials, parts processes, and assemblies, to ensure that our forklift trucks will have a longer life, so that the clients can get more benefits by choosing our products.
Our company has more than 15 years of experience of professional R&D technical team. We are specialized in electric forklift (battery forklift), diesel forklift, manual/electric pallet truck, manual/electric stacker, order pickers, lift table trucks, with capacity from 500kgs to 10000kgs. Most of our products are CE certified. Meanwhile, we have professional technical team in designing and producing which can meet different requirements from customers, to support OEM/ODM service, we offer 24 hours pre-sales and after-sales support, to ensure in-time communication between clients and us.
Our company has more than 15 years of experience of professional R&D technical team. We are specialized in electric forklift (battery forklift), diesel forklift, manual/electric pallet truck, manual/electric stacker, order pickers, lift table trucks, with capacity from 500kgs to 10000kgs. Most of our products are CE certified. Meanwhile, we have professional technical team in designing and producing which can meet different requirements from customers, to support OEM/ODM service, we offer 24 hours pre-sales and after-sales support, to ensure in-time communication between clients and us.
