competitive price fronius inverter solar2000W 2400W 2800W solar invertor
- Category: >>>
- Supplier: Dongguan Linyue Electric Technology Co. Ltd.
Share on (1600793100189):
Product Overview
Description
Products Description
Modell | LY-2000 | LY-2400 | LY-2800 | ||
Recommend PV | MAX 4*625W | MAX 4*750W | MAX 4*875W | ||
PV opencircuitvoltage range | 30-60 VOC | ||||
Min /Max start voltage | 20~60V | ||||
Peakpower tracking voltage | 20~60V | ||||
Maximum DC short current | 4*20 | 4*23 | 4*27 | ||
Maximum Input Current | 4*23 | 4*28 | 4*32 | ||
Power | 2000W | 2400W | 2800W | ||
Output current | @120V 16.6A | @120V 20A | @120V 23.5A | ||
@230V 8.7A | @230V 10.5A | @230V 12.2A | |||
AC Voltage/Frequency Range | @120V 85-160VAC 48-51Hz/58-61Hz | ||||
@230V 180-280VAC 48-51Hz/58-61Hz | |||||
Loss of power at night | <0.5W | ||||
Total current harmonics | <5% | ||||
Power factor | >95% | ||||
Static MPPT efficiency | 99.50% | ||||
Max output efficiency | 95% | ||||
Number of branch connections | @120V 3 PCS | @120V 2 PCS | @120V 2 PCS | ||
@230V 6PCS | @240V 4 PCS | @230V 4 PCS | |||
Working Temperature | -20°C to +50°C | ||||
