High Quality 110kw heat pump water heater

Product Overview

Description

Model			unit	FA-30
Rated heating capacity			KW	110
			BTU	395665
Hot water supply			T/h	2.96
Average heating input power			KW	24.6
Rated heating input current			A	38
Max outlet water temp			℃
COP				4.7
Power			V/Hz
Nosie			dB(A)	63
Dimension		Width	mm	2305
		Deepth	mm	1100
		Height	mm	1860
Unit weight			KG	720
Throttling type				Electronic expansion valves
Refrigerant				R410A, R32
Working air temp range				– 20℃~45℃
Compressor	Type			Scroll Copeland,.hitachi,panasonic
	Security functions			Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect
Air source heat exchanger	Type			Finned heat exchange
	Qty		piece	4
	Fan type			Axial big twist Angle fan
	Motor power		W	550*3
Hot water side heat exchange	Type			tube in shell heat exchanger OR Shell tube heat exchanger
	Water flow		m3/H	18
	Water pressure down		kPa	45
	Pipe size		Inch	3
	Water side max working pressure		kPa	1000
Circulate water pump				No
water flow switch				Yes
FOB Guangzhou			USD	6422
