Rainbow A1 6 Colors G5i Ricoh UV Printer Machine for PVC Ceramic Canvas Glass Furniture Fine Art Prints Nameplates Door Knobs
- Category: >>>
- Supplier: Shanghai Rainbow Industrial Co. Ltd.
Share on (1600795850819):
Product Overview
Description
Optional Accessories
UV curing ink
CMYKLcLmW as one set, 500ml per bottle, can last for 270-370 m2 printing.
Cleaner solution
Cleaning liquid for printhead, can effectively clean the
Laminator
It can laminate the printed UV DTF film A and film B and make stickers.
UV DTF film
Film B for making UV DTF stickers, comes with film A. One set has 100pcs of film A and 50m film B.
Title goes here.
Printhead DX10 for spare use. Other options such as i3200 and Ricoh Gen5i are also available.
Product Description
1. Double Hiwin linear guideways
Nano 9 has 2pcs of Hiwin linear guideways on its X-axis, 2pcs on Y-axis, and 4pcs on Z-axis, makes it a total of 8pcs of linear guideways.
In comparison, most other A1 uv printers has only 3-7pcs of guideways in total, and not necessarily linear ones.
This brings better stability in printer running, thus better printing accuracy, and longer machine lifespan.
2. Thick glass/aluminum vacuum table
The standard Nano 9 is with thick glass table, anti-scratch and anti-corrosion. You can print test bar, or guide lines on it without the worry that it might not be easy to clean.
3. German Igus cable carrier
Imported from German, the cable carrier runs smoothly and quietly, it protects the ink tubes and cables during the printer carriage movement, and it has long lifespan.
4. Low Ink alarm system
8 lights for 8 kinds of ink make sure you will notice the ink shortage when it does, the ink level sensor is placed inside the bottle so it can detect accurately.
5. 6 colors+White+Varnish
CMYKLcLm+W+V ink system now has Lc and Lm 2 extra colors to improve the color accuracy, making the printed result even sharper.
Feel free to ask for the color test print from our support team to examine the result.
Feel free to ask for the color test print from our support team to examine the result.
6. Carraige plate temperature controler
It's a compact device inside the printer carriage that serves to 1)heat the metal carriage bottom plate and 2)display the real time temperature of the carriage bottom plate.
7. UV LED lamp power knobs
There are two UV LED lamps in Nano 9 for color+white and varnish respectively. Thus we designed two UV lamp wattage controlers. With them, you can adjust the wattage of the lamps according to your jobs' requirement.
For example, if you need to print heat-sensitive materials like film A&B(for stickers), you might want to turn down the lamp wattage to prevent it from altering its shape because of the heat.
For example, if you need to print heat-sensitive materials like film A&B(for stickers), you might want to turn down the lamp wattage to prevent it from altering its shape because of the heat.
8. Full rotary support
Nano 9 also supports rotary printing with the help of the rotary device. It can handle three kinds of rotary products: the bottle with a handle like mug, the bottle without a handle like normal water bottle, and the tapered bottle like tumbler.
It's convenient to install and uninstall the device, just need to put it on the platform and the magnet will fix the device in place. Then we need to switch the print mode to rotary and we'd be able to do the print just as usual.
It's convenient to install and uninstall the device, just need to put it on the platform and the magnet will fix the device in place. Then we need to switch the print mode to rotary and we'd be able to do the print just as usual.
9. Embossing/Varnish supported
Nano 9 is capable of realizing the above special prints: embossing, varnish/glossy. And we have the respective video tutorials to show you step by step.
Glitter Golden Powder Effect
Fluorescent Effect
10. Special UV Results Supported
With special methods, Nano 9 is capable of realizing the above effect, adding new value to your works!
Specification
Name | Nano 9 | ||
Printhead | 2-4pcs Epson DX10/XP600 | ||
Resolution | 720dpi-2880dpi | ||
Type | UV LED Curable Ink | ||
Package volume | 500ml per bottle | ||
Ink supply system | CISS Built Inside Withi Ink Bottle | ||
Consumption | 9-15ml/sqm | ||
Ink stirring system | Available | ||
Horizontal | 60*90cm(24*37.5inch;A1) | ||
Vertical | substrate 16cm(6inches) /rotary 12cm(5inches) | ||
Type | Metal, Plastic, Glass, Wood, Acrylic, Ceramics, PVC, Paper, TPU, Leather, Canvas, etc. | ||
Weight | ≤20kg | ||
Media (object) holding method | Glass table/ Aluminum vacuum table | ||
RIP | Photoprint/Ultraprint | ||
Control | Print Dream | ||
format | TIFF(RGB&CMYK)/BMP/ PDF/EPS/JPEG... | ||
System | Windows XP/Win7/Win8/win10 | ||
Interface | USB 3.0 | ||
Language | Chinese/English | ||
Requirement | 50/60HZ 220V(±10%) ＜5A | ||
Consumption | 500W | ||
Assembled | 1130*1400*720mm | ||
Operational | 1530*1450*850mm | ||
Weight | 135KG/180KG | ||
The machine would be packed in solid wooden crate for international shipping, suitable for sea, air and express transportation.
Package size: 155.5×151.5×81.5cm
Package weight: 224KG
Our Company
Q1:What materials can UV printer print?
A:UV printer can print almost all kinds materials, such as phone case, leather, wood,plastic, acrylic, pen, golf ball, metal, ceramic, glass, textile and fabrics etc.
Q2:Can UV printer print embossing 3D effect?
A:Yes, it can print embossing 3D effect, contact us for more information and printing videos
A:Yes, it can print embossing 3D effect, contact us for more information and printing videos
Q3:Can A3 uv flatbed printer do rotary bottle and mug printing?
A:Yes, both bottle and mug with handle can be printed with the help of rotary printing device.
Q4:Does printing materials must be sprayed a pre-coating?
Q4:Does printing materials must be sprayed a pre-coating?
A:Some material need pre-coating, such as metal, glass, acrylic for make the color anti-scratch.
Q5:How can we start to use the printer?
A:We will send the detailed manual and teaching videos with the package of the printer before use the machine, please read the manual and watch the teaching video and operate strictly as the instructions, and if any question unclarified, our technical support online by teamviewer and video call will be help.
Q6:What about the warranty?
A:We have 13 months warranty and lifelong technical support, not include consumables like print head and ink
dampers.
dampers.
Q7:What's the printing cost?
A:Usually,1 square meter need cost about $1 printing cost with our good quality ink.
Q8:Where can I buy the spare parts and inks?
Q8:Where can I buy the spare parts and inks?
A:All spare parts and ink will be available from us during the whole lifespan of printer, or you can buy at local.
Q9:What about maintenance of the printer?
A:The printer has auto-cleaning and auto keep wet system, each time before power off machine, please do a normal cleaning so that keep print head wet. If you don't use the printer more than 1 week, it’s better to power on machine 3 days later to do a test and auto clean.
