Hot sale Low voltage Split Core CT Wireless busbar Power Supply DC Current Transformer

Split Core current sensor supplier, split core current transformer manufacturer

Small size, low cost
High secondary turns
Secure locking hinge

Features:
Maximum continuous primary current 50AAC
Current Ratio: 3000: 1
Output: 16.67mA at rated current
Accuracy: ± 1% from 5% to 120% of rated current
Insulation Voltage: 600VAC
Maximum Primary Voltage: 5000VAC(Insulated Conductor)
Phase angle: Less than 2 degrees at 50% of rated current
Frequency Range: 50 Hz to 400 Hz
Operating Temperature: -15C to 60C.
Leads: 4Foot(105cm), UL 1015, Twisted Pair, 0.34 mm2(22AWG)
CE recognized, and RoHS compliant
Output and leads can be customized

SCT-T10  5-80A current, with 0.33v or mA output Split core current transformers

SCT-T16 5-120A current, with 0.33v or mA output Split core current transformers

SCT-T24 5-300A current, with 0.33v / mA/5A/1A output Split core current transformers

SCT-T36 5-300A current, with 0.33v / mA/5A/1A output Split core current transformers

SCT-T50 100-1000A current, with 0.33v / mA/5A/1A output Split core current transformer

SCT-T70 100-1200A current, with 0.33v / mA/5A/1A output Split core current transformer

FSCT-36 100-800A current, with 5A/1A output Split core current transformer

Rogowski coils with 0.33v /5v/4-20mA output

Certifications
