Corrosion Resistance PTFE Sodium Board Anti Corrosion and High Temperature Resistant Adhesive Plastic PTFE Plate Etched Sheet

Product Overview

Description

Product Description



ETECHED PTFE SHEET
PTFE Etched sheet is prepared by the technology of chemical treatment on one side or two sides of molded sheet or skived PTFE Sheet. Common adhesive such as epoxy or PU type adhesive can be applied on the chemical treated PTFE surface that can laminate steel and rubber sheet. It conforms to the enterprise standard Q/GHAD7-2000.
Application:

These PTFE laminated sheets can be used as bridge slide block,anti-corrosive sealingt and diaphragm value etc.



Feature:

1. Anti-flaming
2. Insulation
3. Anti-aging
4. Corrosion resistant



Main indexes

Item	Unit	Result
Apparent density	g/cm3	2.10-2.30
Tensile strength	MPa	≥15.0
Tear elongation	%	≥150
Temperature range	℃	-180~+260



PTFE Sheet Type	Thickness	Width and Length Range
PTFE Skived Sheet	0.1- 7mm	Width from 10 to 2000mm Length 1Meter~50 Meters
PTFE Molded Sheet	8mm to 400mm	Standard Width*Length 250 x 250mm 300 x 300mm 500 x 500mm 600 x 600mm 800 x 800mm 1000 x 1000mm 1200 x 1200mm 1200 x 1800mm 1500 x 1500mm 1000 x 2000mm
