Rubber Internal Mixer Machine / plastic internal machine /Banbury rubber kneader internal mixer

Product Overview

Description

Rubber Internal Mixer Machine / plastic internal machine /Banbury rubber kneader internal mixer



Company Introduction



Qingdao Huachuan Machinery Co., Ltd. is one of the important backbone enterprises in rubber machinery industry in China and is the member of Shandong machinery union company.







Our company owns powerful technical strength, advanced techniques, the best design and a strict quality guarantee system, and owns a high reputation in Chinese rubber machinery industry.





Our company owns powerful technical strength, advanced techniques, the best design and a strict quality guarantee system, and owns a high reputation in Chinese rubber machinery industry.





The main products are plate vulcanizing presses, open rubber mixing mills, Banbury intensive kneaders, extruders and rubber and reclaimed rubber machinery.



The products have been sold to more than 20 provinces and cities in China and have been exported to more than 10 countries and areas. All of the products are designed visually by three-dimension CAD design, quickly built module, limited element analysis, analogue action and interfering inspection.









This machine is suitable for reclaimed rubber plants, transmission belt factory, conveyor belting factory, rubber products factory, shoe factory,cable factory, rubber hose factory, seals and rubber related industry.It is mainly used for the mixing of natural rubber or reclaimed rubber after desulphurization to mixing ,plastic refining and tablet.







Main Features :



A. The roll adopts the vanadium titanium metal alloy chilled cast iron and its surface is hard and wear-proof. The internal cavity is processed to make temperature well proportioned on the roll surface.



B. The machine is equipped with an overload protection device to prevent the main components from



C. The machine is also equipped with an emergency brake device. When an emergent arises, just draw the safety pull rod, and the machine will stop immediately. It is safe and reliable.



Main Technical Parameter:



Type		XS(N)-20* 34	XS (N)-35*30	XS (N)-55*30	XS (N)-75*30
Pinching total cubage	L	45	75	125	175
Dence smelting total cubage	L	20	35	55	75
Main moter power	KW	22	55	75	110
Overtum moter power	KW	1.5	2.2	2.2	3.0
Overtum angle	°	140°	140°	140°	140°
Rotate speed of rotor axis	r/min	34/28	30/24.5	30/24.5	30/24.5
Pressure of compressing air	Mpa	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Pressure of cooling water	Mpa	0.2-0.4	0.2-0.4	0.2-0.4	0.2-0.4
Pressure of heating vapour	Mpa	0.5-0.8	0.5-0.8	0.5-0.8	0.5-0.8
Extemality dimension	mm	3100*1300*2450	3200*1900*2945	3300*1900*2900	3760*2143*3135
Weight	kg	4500	6500	7800	10230
