High quality Automatic benchtop glue dispensing robot for AB cartridge
- Category: >>>
- Supplier: Shenzhen Robotsung Automation Technology Co. Ltd.
Share on (1600799566671):
Product Overview
Description
Company Profile
Product Description
Advantages:
1. Full-automatic glue dispenser can dispense through 3D and 4D path. It can quickly draw dot, line circle and all kinds of
irregular figures on the surface, vertical plane, gap and spherical surface.
2. Graphics import or machine screen edit, easy to operate with high precision.
3. Big scale workstation can place multiple products, which is more efficient. Workstation can be customized according to the size
of product.
4. Glue dispenser can be equipped with several dispensing heads and operate at the same time, greatly increasing dispensing
efficiency.
5. Glue dispenser is applicable for all kinds of glue. Dispensing liquid such as oil paint and printing ink needs to equip
additional high-capacity pressure barrel to reduce glue changing time.
6. We are a manufacturer with more than 20 years of production experience. We have excellent R&D and production ability, sound QC
system and perfect after-sale service. Robotsung has become a nationwide famous brand in China.
Application:
1. Electro-acoustic industry: horn, loudspeaker, buzzer, earphone.
2. Inductance industry: small transformer, SMD transformer, inductance, relay, small coil motor.
3. Communication industry:keypad, phone shell,interphone,telephone, fax machine.
4. Computer, digital products, digital camera, MP3, MP4, electronic toy, chassis adhesion.
5. Switch, connector, wire rod, plug cable.
6. Electronics: electron component, integrated circuit, circuit board solder paste, LCD screen, etc.
7. Optics: optical lenses, magnetic head.
8. Mechanical hardware, battery box sealing, label fixing adhesion, car parts coating.
9. Food packaging.
10. LED industry.
Applicable glue:
Silicon, UV glue, AB glue, epoxy resin, instant glue, EMI conducting resin, sealant, hot glue, grease, red gum , solder paste,
thermal grease, solder grease, lacquer, screw fixing agent.
irregular figures on the surface, vertical plane, gap and spherical surface.
2. Graphics import or machine screen edit, easy to operate with high precision.
3. Big scale workstation can place multiple products, which is more efficient. Workstation can be customized according to the size
of product.
4. Glue dispenser can be equipped with several dispensing heads and operate at the same time, greatly increasing dispensing
efficiency.
5. Glue dispenser is applicable for all kinds of glue. Dispensing liquid such as oil paint and printing ink needs to equip
additional high-capacity pressure barrel to reduce glue changing time.
6. We are a manufacturer with more than 20 years of production experience. We have excellent R&D and production ability, sound QC
system and perfect after-sale service. Robotsung has become a nationwide famous brand in China.
Application:
1. Electro-acoustic industry: horn, loudspeaker, buzzer, earphone.
2. Inductance industry: small transformer, SMD transformer, inductance, relay, small coil motor.
3. Communication industry:keypad, phone shell,interphone,telephone, fax machine.
4. Computer, digital products, digital camera, MP3, MP4, electronic toy, chassis adhesion.
5. Switch, connector, wire rod, plug cable.
6. Electronics: electron component, integrated circuit, circuit board solder paste, LCD screen, etc.
7. Optics: optical lenses, magnetic head.
8. Mechanical hardware, battery box sealing, label fixing adhesion, car parts coating.
9. Food packaging.
10. LED industry.
Applicable glue:
Silicon, UV glue, AB glue, epoxy resin, instant glue, EMI conducting resin, sealant, hot glue, grease, red gum , solder paste,
thermal grease, solder grease, lacquer, screw fixing agent.
Specification
Model | YS-D331E | YS-D441E | YS-D551E | YS-D461E | |||
Working Area | 300*300*100 | 400*400*100 | 500*500*100 | 400*600*100 | |||
Control System | Independent R D | ||||||
Driver | Stepper Motor+ Silver Guideway+Timing Belt | ||||||
Repeatablity | +/-0.02-0.05mm | ||||||
Air Pressure | 0.4-..7Mpa | ||||||
Speed | 500mm/s | ||||||
Power | 220V/110V 50/60HZ 350W | ||||||
Max Load | XYZ 10KG | ||||||
Display | 5.7 inch Screen | ||||||
Program Method | Screen operation /connect to PC | ||||||
File Total | Number unlimited,16M | ||||||
I/O Signal | 16 inputs/16 outputs | ||||||
Weight | 35KG | 45KG | 55KG | 65KG | |||
Size | 680*570*680 | 780*670*680 | 880*770*680 | ||||
Packing & Delivery
Package will be hard carton with Foam Filled, Wood Package if nessesory.
Lead Time: 3-5 Days, if Customized, be negotiated.
FAQ
1. Why choose us?
We provide overall solutions for processing equipment. Our standard equipment is very complete, all are in stock and can beshipped quickly. We have our own equipment factory, which can lightly customize equipment according to customer requirements, suchas ordering different appearances and brands for agents, and non-standard equipment according to customer requirements.
2. Should I worry about the quality?
Before delivery, we do test the machine working condition for you.
We provide overall solutions for processing equipment. Our standard equipment is very complete, all are in stock and can beshipped quickly. We have our own equipment factory, which can lightly customize equipment according to customer requirements, suchas ordering different appearances and brands for agents, and non-standard equipment according to customer requirements.
2. Should I worry about the quality?
Before delivery, we do test the machine working condition for you.
Take a video of the normal operation of the machine to you, and then confirm the delivery
3.How can I know your machine is designed for my product?
You tell us the specific parameters of your product, or you can send us samples of your product and we test it on machine. Video for you to make samples
4. How to operate the equipment?
My friend, don't worry about it, we have made vedio for you, it will show you how to do it step by step. Contact our engineers at any time when you don’t understand, support video and telephone communication
5.When the machine can't work well,What should I do?
The Engineer is online for 24-hours, they can check the problems and then give you solution way very soon. Please rest assured that manual will be offered along with machine,ensuring you can operate the machine easily.
3.How can I know your machine is designed for my product?
You tell us the specific parameters of your product, or you can send us samples of your product and we test it on machine. Video for you to make samples
4. How to operate the equipment?
My friend, don't worry about it, we have made vedio for you, it will show you how to do it step by step. Contact our engineers at any time when you don’t understand, support video and telephone communication
5.When the machine can't work well,What should I do?
The Engineer is online for 24-hours, they can check the problems and then give you solution way very soon. Please rest assured that manual will be offered along with machine,ensuring you can operate the machine easily.
