Интеллектуальный цифровой 4 20ma RS485 дифференциальный датчик давления, цена

AP2001-

AP2001 Differential Pressure Transmitter

Code 1

Accuracy

C

±0.1%

Code 2

Range (when no migration)(kPa)

B

0~1-6

C

0~4-40

D

0~25-250

F

0~250-3000

Code 3

Output

1

4mA-20mADC

2

485 Communication

3

4mA-20mADC/485 Communication

Code 4

Isolate Diaphragm

S

316L Stainless Steel

H

Hastelloy C

Code 5

Filling Fluid

1

Silicon Oil

2

Fluorine Oil

Code 6

Rated Working Pressure

A

16MPa

B

40MPa

Code 7

Process Flange

1

1/4NPT and M10 threaded holes, no relief valve

2

1/4NPT and M10 threaded holes, rear end relief valve

Code 8

Wet sealing material

A

Nitrile rubber(NBR)

B

Fluorine rubber(FKM)

C

PTFE

Code 9

Electrical Interface

1

M20×1.5 Female thread (with cable sealing head)

2

NPT1/2 Female

Code 10

Mounting Bracket and Material

A

None

B

Carbon steel mounting bracket

C

Stainless steel mounting bracket

Code 11

The bit number Location

1

None

2

Hanging stainless steel standard

Code 12

Manual

A

Chinese

B

English
