Portable Medical Syringe Pump Iv Syringe Infusion Pump For Hospital Injection Pump With Single Channel
- Category: >>>
- Supplier: Anjue Medical Equipment Co. Ltd.
Share on (1600813266201):
Product Overview
Description
FEATURES
1. Freely Stackable: Users can freely stack one syringe pump onto another to provide multiple Solutions, which have a wide range of clinical applications.
2. Stackable to be the maximum 8 channels.
3. Transfer the message between the Nurse-call System and the pumps.
4. Three working modes: rate mode, time-volume mode, dosage-weight mode.
5. Unique Voice Alarm system and accurate injection rate make the injection process safer and more reliable.
6. Have store many brands syringes, Automatically calibration and compatible with any brand syringes.
7. Large LCD screen displays working status.
8. KVO and Bolus functions.
9.Has drug library with more than 500 drugs.
10.Has 2000 records.
SPECIFICATION
Product name | Stackable syringe pump with drug library AJ-P900G |
Unique Voice Alarm system | The device triggered the voice prompt and stop injection automatically when there is any malfunction, making the infusion process safer and more reliable. |
Flow rate | 50ml syringe:0.1~1500ml/h; 30ml syringe:0.1~900.0ml/h; 20ml syringe:0.1~600.0ml/h; 10ml syringe:0.1~300.0ml/h |
The range of limiting volume | 0~999.9ml |
The range of injected volume | 0~9999.9ml |
Accuracy of flow rate | Within ±3%(Choose the syringe of specified manufacturer correctly. This accuracy of flow rate is not including the errors of syringe itself.) |
Purge rate | Purge rate of 50ml syringe:1500ml/h; Purge rate of 30ml syringe:900.0ml/h; Purge rate of 20ml syringe:600.0ml/h; Purge rate of 10ml syringe:300.0ml/h |
Alarm and warms | The pump can give out alarming when injection soon finish, injection finishing, injection of limited amount finished, injection is blocked, syringe falls off, syringe is improperly installed, setting error, AC power has been pulled out, low battery and so on. |
Injection blocked | Choose in the three kinds of occlusion alarm pressure according to the clinical requirements(High,Medium,Low) |
KVO rate | 1ml/h |
Fuse specification | F1AL/250V ,two fuses(installed inside pump) |
Operating power | AC100~240.0V, 50/60Hz, Power:≤30VA Internal rechargeable battery: DC 11.1V,capacity≥1600mAh. The device could work constantly more than 4 hour at medium speed running mode, after the battery charged for 10 hours. |
Operating environment | temperature:+5~+40°C, relative humidity:20~90% |
Storing environment | temperature:-30°C~+55, relative humidity:≤95%, ( No condensation state ) |
Atmospheric pressure | 860hPa~1060hPa |
Safety level | Class II with insulated enclosure, internal power supply, BF-type continuous normal running equipment. |
IP grade | IPX1 |
Dimensions | 280(L)×210(W)×130(H)(mm) |
Weight | 2.2kg |
Accessories | Power line,operating manual,warranty card,product certification. |
lient's Feedback:
Advantages:
1.Our medical equipment have been exported many countries,more than 168 countries, such as Philippines, Indonesia, Pakistan, Nigeria, Sudan and many other countries.
2.Not only manufacturing the different types of ventilator,but also supplying other kinds of medical equipment,it's easy to choose what you want models in one company,save time , save money.
3.It has been about 10 years,since we established the company.During these years,no any quality complaint about our machine .
4. Updated over 5 new models every year,and do the research in the medical research.
5.Attending 2 exhibition per year,to broadcast the new technical models.
6.Marked with CE&ISO certificate.
7. The main parts are imported from Germany ,Japan.
