Product Overview
Description
1000 degree fireplace used calcium silicate fireproof board
Calcium silicate fireproof board is mixed with xonotlite and reinforced glass fibre with high service temp. (1050℃), good heat insulation, low bulk density, high strength, good durability and so on.
Product Characteristics:
l Good durability, can bear high temperature within the limit of continuous heat load.
l Low thermal conductivity, in the whole range is used with unmatched adiabatic performance.
l Light weight, high strength. It is the highest in these hard thermal insulation products.
l Better durability, use for a long time without powder.
l Construction with ordinary carpenter applicability, tools can be optional to cut products.
l Used safety, hygiene. Excluding asbestos, sulfur, chlorine such poisonous substances.
l Fear water, but after drying also can be used.
Chemical Composition
SiO2 | CaO | Al2O3 | MgO | Fe2O3 | Na2O+K2O | L.O.I |
48~52% | 44~47% | 3% max | 2% max | 0.5% max | 0.2% max | 8~12 |
Physical Properties
Item | Unit | Index | |
Bulk Density (max) | Kg/m3 | 220 ± 10% For size equal to or smaller than 610x300mm | 250 ± 10% For size equal to or bigger than 1000 x 500mm |
Flexural Strength (min) | Mpa | 0.5 | 0.8 |
Linear shrinkage (max) after heating for 3 hrs at 1000℃ |
% |
2 | |
Thermal conductivity (max) Average temperature 70℃ |
w/m.k | 0.058 + 0.00011t | |
Max. Service Temperature | ℃ | 1000 | |
