Electrical system | Electric control | 60V full intelligent electric control | ||||||||||||||
Battery | 12V100AH/pc, 5pcs/60V(Maintenance-free battery) | |||||||||||||||
Motor | customize | |||||||||||||||
Charger | Car smart charger | |||||||||||||||
Charge Time | 8--9hours | |||||||||||||||
Charging input voltage | 220V | |||||||||||||||
Technicial Data | Rated occupant | 6 | ||||||||||||||
L * w * h | customize | |||||||||||||||
Driving Mileage | 70-110km | |||||||||||||||
System voltage | 48V / 60V /72V | |||||||||||||||
Minimum turning radius | 5.6m | |||||||||||||||
Climbing Ability | ≥ 20% | |||||||||||||||
Braking distance | ≤ 5m | |||||||||||||||
Max speed | 30Km/h | |||||||||||||||
Power of motor | 3.5KW | |||||||||||||||
Curb Weight | 600KG | |||||||||||||||
Wheel base | 3100mm | |||||||||||||||
Front Rear Tracks | 900/1000mm | |||||||||||||||
Body system | Seat Material | Joint seat (leather fabric + high rebound PU seat) | ||||||||||||||
Car body | Steel frame + injection molded housing / ABS engineering plastic molding parts | |||||||||||||||
Instrument Panel | Digital display LCD instrument(including voltage, speed, mileage, light, front and rear direction signals) | |||||||||||||||
Steering wheel | Car steering wheel | |||||||||||||||
Lights and signals | LED combination headlight, turn signal, combination taillight, brake lamp, electric horn | |||||||||||||||
Switch System | Start the switch, light, advance and retreat switch | |||||||||||||||
Frame | Steel structure frame | |||||||||||||||
Steering wheel | Polyurethane foam steering wheel | |||||||||||||||
