Product Overview
Description
Products Description
Display: | 7-inch large touch display | Scanning mode: | 3.5m mechanical fan scanning | |||
Operation interface: | 6 languages can be customized, user-friendly operation interface, quick start; | Display mode: | B, B+B, 4B, B+M, M; | |||
Electronic focusing: | four-segment electronic focusing | Body position markers: | ≥18 kinds | |||
Frequency conversion: | any probe has a five-segment frequency conversion function; | Image mirroring: | rotate the mirror up, down, left and right, and the interface can be flipped in black and white; | |||
Body position markers: | ≥ 18 types | Conventional measurement: | distance, perimeter, area, volume, angle; | |||
Character display: | gain, frequency, dynamics, date, time; | Maximum display depth: | 3.5MHz: 270mm 6.5MHz: 189mm 7.5MHz: 165mm | |||
Storage: | Built-in 8G storage, external U disk storage, you can browse pictures locally, and transfer the built-in pictures to U disk; | Gain range: | 0～100dB; | |||
Dynamic range: | 0-135dB | Blind zone: | ≤4 | |||
Main Features: 1The screen can be rotated 180 degrees, the touch foot point and the display interface are all rotated, which is convenient for the operator to use with the left or right hand; 2.Button + touch screen, multiple operation modes, simple and fast 3.With image rotation function, the image can be flipped up and down, left and right; 4.Image processing: gamma correction (0-7), frame correlation (0-3), line correlation (0-5), edge enhancement (0-3), left and right flip (0-1), sixteen kinds of pseudo-color deal with; 5.Geometric accuracy: horizontal ≤ 5%, vertical ≤ 5% . Resolution: lateral ≤2mm, axial ≤1mm6.Near field adjustment range: -31~0; . Far-field adjustment range: 0~31; | ||||||
