Control P2.5 LED Digital Billboard Iron LED Signs Outdoor Programmable Column Fixed 4G Video Wall Display IP65 2 Years 2.5 Meter
- Category: >>>
- Supplier: Shenzhen Topwill Technology Co. Ltd.
Share on (1600822844495):
Product Overview
Description
Applications
Outdoor fixed LED screen features
Higher Refresh Rate
The refresh rate is up to 4K Hz. The LED screen displays smooth and stable videos and images without flicker and ghosting.
Higher Gray Scale and Higher Contrast Ratio
The LED screen has better performance on displaying colors from dark to light and shows more colors' details.
Wider viewing angle
The LED screen has wider viewing angle. It is up to 160o in horizontal direction and 120o in vertical direction. More audiences can watch messages, images, videos etc. on the LED display.
Higher brightness and auto brightness
The outdoor LED screen has higher brightness so that it can be visible at daylight even facing to the sunlight. With auto brightness function, it will adjust brightness at nighttime to protect pedestrians and drivers and save energy.
Waterproof and dustproof
IP65 and IP67 protection
With high protection level and special raw material, the LED screen has great performance and adapt to a variety of installation environments.
High efficiency cooling
4pcs powerful aerofoil fans
With powerful cooling system, it can keep the inside temperature lower to make sure that the LED screen has a long service life.
Seamless without gaps
CNC Machining
High-quality raw materials, large-scale production ensure stable and reliable quality cabinets which keep the LED screen in a good shape and smoothly. It leaves no obvious gaps between each cabinets.
Standard and customized size
Standard size:
768x768 mm (30.24x30.24 inches)
960x960 mm (37.8x37.8 inches)
1024x1024 mm (40.31x40.31 inches)
We can also make customization
768x768 mm (30.24x30.24 inches)
960x960 mm (37.8x37.8 inches)
1024x1024 mm (40.31x40.31 inches)
We can also make customization
High Brightness VS Low Brightness
High brightness LED display has better performance than low brightness.
Low maintenance cost
Both back side and front side maintenance service
It's easy and quick to replace broken modules and other components.
It's easy and quick to replace broken modules and other components.
LED display component
LED display components are LED display module, cabinet or frame, control system, video processor, power system, cables and screws.
LED display module is the most important component.
P2.5 LED display module features: | ||
Pixel pitch: | 2.5 mm | |
LED type: | SMD1921 | |
LED composition: | SMD 3IN1 (1R 1G 1B) | |
Module size: | 320 x 160 mm | |
Module resolution: | 128 x 64 pixels | |
Module pixels: | 8,192 pixels | |
Density: | 160,000 pixels/m2 | |
Control System
Synchronous Control and Asynchronous Control.
Brand: Novastar, Huidu, Sysolution and Linsn etc.
Video Processor
Support multi video input and video solution.
Brand: Kystar, Vdwall and Novastar etc.
Power Supply
Stable power output for LED display.
Brand: Meanwell, G-energy and Chuanglian etc.
72 Hours Aging Test
72 hours aging test is the most important in productions. During this procedure, we can check if any LEDs go wrong.
Normally it is Red color, Green color, Blue color, White color and full color videos display testing.
Waterproof Test
Waterproof test ensures that the LED display can reach IP65 level.
Factory Tour
Package and Shipment
Carton Box Package
7 layers with EPE foam inside, strong and safety for long distance shipment.
Plywood Package
One time usage, EPE foam inside, cheap and safety for long distance shipment.
Flight Case Package
Reuse, EPE foam inside, movable, expensive and safety for long distance shipment.
Air shipment and express such as DHL, Fedex, UPS, TNT are fast delivery and expensive.
Sea shipment is low cost and long time delivery.
