Product Overview

Description



Product Paramenters


High Voltage Current-Limiting Fuse XRNP---------Customization Service

Voltage: 3.6KV/7.2KV/10KV/20KV/24KV/35KV/40.5KV
Current: 0.5-3.15A/5-25A
Dimension: 25*195/25*354/25*465/51*192/51*510

Special size please contact our sales.








current limit fuse fuse xrnp cylindrical fuse 11kv fuse voltage transformer fusibles para transformadores en aceite xrnp high voltagefuse xrnp fuse voltag fuse mediumfuse voltag high fuse shorty 83kvafuse shorty backup clf high tec fuse industrial fuse siba 10kv fuse fuse 10 kv of voltage transformers high tec fuseeaton fuse clip fuse clip 24kv


Products Description




The product can be used in system with AC50Hz and rated voltage of 10KV,used together with other protection facilities(such as loading switches).It can protect electric transformers and other electric facilities against overloading or circuit break.It is mainly used in American box type transformers as backup protection.


model
rated
voltage
(kv)
rated current
of fuselink
(A)
Rated
breaking
current
(KA)
Dimensions
(mm)
weight
XRNP1
3.6
0.5,1,2,3,15,6.3
50
See figure 1 142
0.19
XRNP1
7.2
0.5,1,2,3.15
50
see figure 1 142(195)
0.19(0.22)
XRNP1
12
0.5,1,2,3.15
40
See figure 1 195
0.22
XRNP1
24
0.5,1,2,3.15
40
See figure 1 355
0.43
XRNP1
40.5
0.5,1,2,3.15
31.5
See figure 1 465
0.55
XRNP1
12
0.5,1,2,3.15
50
See figure 1
1.12




Product packaging






Company Profile






Exhibition and Package




FAQ


Q1: What's your material?
A1: We use high-strength porcelain and silver wire to ensure that the circuit is disconnected in time when overloaded.

Q2: What sizes do you have?
A2: These are our normal size: 51*292/63*292/76*292/88*292/51*442/63*442/76*442/88*442/ 51*537/63*537/76*537/88*537. Dimension,
Color, Package can be customized.

Q3: What's your MOQ?
A3: 100PCS

Q4: How long will you delivery?
A4: If within 5 pcs for sample, we can ship the next day after payment. If bulk, please ask for sales.

Q5: Can you quote FOB?
A5: We can quote EXW, FOB, CIF, CFR. International Express Available, FedEX, UPS, DHL.
