Heavy Duty 12000N DC Brush Linear Actuator Motor 12V 24V 1000mm Stroke Linear Actuator
- Category: >>>
- Supplier: Changzhou Changxing Motion Tech Co. Ltd.
Share on (1600823630499):
Product Overview
Description
Product Description
The provided industrial linear actuator is a very powerful actuator, due to its 12000N large load capacity, compact design, and IP66 rated protection, is ideal for various applications such as agricultural machinery, construction machinery, and industrial machinery.
Application of linear actuators
* Lift of flaps in motor vehicles
* Components of industrial and agricultural machinery
* Domestic and industrial automation components
* Opening and closing of valves
* Photovoltaic components
* Lift of flaps in motor vehicles
* Components of industrial and agricultural machinery
* Domestic and industrial automation components
* Opening and closing of valves
* Photovoltaic components
item | SLA-12K linear actuator | ||||
Maximum push/pull force | 1200kg/12000N | ||||
voltage | 12V/24V/36V/48VDC | ||||
Standard stroke | S = (50, 100, 150,200,300,400, 600,800,1000) mm, can be customized according to customer requirements. | ||||
The shortest installation distance (the distance between the centers of the front and rear holes when the inner tube is fully retracted) | L=Stroke + 250 mm (Stroke<300mm) L=Stroke + 260 mm (Stroke>300mm) | ||||
the center distance between the front and rear holes when the inner tube is fully extended | 2*S (stroke) + 250mm/260mm | ||||
No-load speed | maximum 20mm/s | ||||
Rated load rate | 5mm/s (12000KG) -20mm/s (200KG) | ||||
Ambient temperature | -26℃~45℃ | ||||
Standard protection level | IP66 | ||||
limit switch | Built-in | ||||
Low noise design | the noise level is 60dB | ||||
controller | Can be equipped with wire or wireless remote control | ||||
Certifications | CE | ||||
Company Profile
Our company is a professional manufacturer of linear actuators, we are focusing on providing quality products and satisfied after-sale service for our customers.
After many years developing, now we have high quality products and professional sales man to help our customer make right choice of linear actuators and related products.
Our products now are exported to many countries around the world.
We welcome your coming, build new business relationship and cooperate for mutual benefits
After many years developing, now we have high quality products and professional sales man to help our customer make right choice of linear actuators and related products.
Our products now are exported to many countries around the world.
We welcome your coming, build new business relationship and cooperate for mutual benefits
Related Products
After Sales Service
FAQ
Necessary elements to select a suitable linear actuator type
1） stroke length: the length that shaft moves from one end to another end
2) Travel speed is associated with the load for one type product ,High speed and lower load.
3) Input voltage is DC voltage.
1） stroke length: the length that shaft moves from one end to another end
2) Travel speed is associated with the load for one type product ,High speed and lower load.
3) Input voltage is DC voltage.
