Interface Name | Function |
DB9 (CN1)/(Female socket) | Two RS485 interfaces, supporting the MODBUS protocol |
CN2 | One CANopen/CANlink |
Ethernet port (CN4) | EtherCAT protocol |
Ethernet port (CN3) | 1. MODBUS TCP 2. Standard Ethernet function 3. System program debugging 4. User program downloading and debugging (only supporting IPv4) |
USB | Program downloading and debugging |
High-speed I/O | 16-point high-speed input 8-point high-speed output |
I/O indicator | 16-channel input and 8-channel output signal valid indicator |
DIP switch | RUN/STOP DIP switch |
SD card interface | Stores user programs and data |
MFK key | MFK multi-function key |
Pin | Signal | Signal Direction | Signal Description |
1 | TD+ | Output | Data transfer+ |
2 | TD- | Output | Data transfer |
3 | RD+ | Input | Data receive+ |
4 | -- | -- | Disabled |
5 | -- | -- | Disabled |
6 | RD- | Input | Data receive– |
7 | -- | -- | Disabled |
8 | -- | -- | Disabled |
