Круглое сито из нержавеющей стали
- Category: Mining Machinery >>>
- Supplier: Xinxiang Yuecheng Machinery Co. ltd.
Share on (1600827754137):
Product Overview
Description
Working principle: Stainle steel pharmaceutical Food flour round screener separator rotary ultrasonic vibrating screen sieve sifter
Artech telsonic ultrasonic vibrating screen sieve machine is a kind of high precision sieve filter machine, which uses both the vertical vibrating motor and ultrasonic transmitter as its vibrating source. By adding the ultrasonic wave to the screen, it can be widely used in any industries needing to sieve and filter high value-added micro powder.
Feature.
1.The parts in contact with the material can be made of high-quality Q235 carbon steel, stainless steel 304, stainless steel 316L
2.The unique automatic flanging design prevents the storage of materials between the mesh frame and the screen frame, which is especially suitable for food, medicine and other industries.
2.The unique automatic flanging design prevents the storage of materials between the mesh frame and the screen frame, which is especially suitable for food, medicine and other industries.
3.Discharge port can be adjusted in 360 degrees. machine structure has no dead ends, easy to clean and disinfect thoroughly.
4. The mesh can be customer made, 500 mesh is available, slurry filtration can reach 25 microns. 5. Special grid design. It can be used in single or multiple layers.
6. The screening process is fully enclosed, no powder and liquid spillage, production environment highly improved.
4. The mesh can be customer made, 500 mesh is available, slurry filtration can reach 25 microns. 5. Special grid design. It can be used in single or multiple layers.
6. The screening process is fully enclosed, no powder and liquid spillage, production environment highly improved.
7.The machine is automatic operation, no specialties required, easy assemble and disassemble, suitable for assemble line production.
Parameters:
Type | Parameter | Type | Parameter |
Frequency | 35KHZ | Dimension | 300*300*300mm |
Power | 220CV-240CV 50/60Hz | Housing | IP65 |
Work Model | Continuous Work | Adjustment Range | 50-100% |
Max Environment Temperature | -10-45 degree C | Resonator | Plug-type |
Model No. | Power(Kw) | Screen surface diameter (mm) | Effective area (m2) | Dimension (mm) | Layer |
SC-600-1S SC-600-2S SC-600-3S | 0.55 | 550 | 0.2374 | 800*800*680 800*800*780 800*800*880 | 1-3 |
SC-800-1S SC-800-2S SC-800-3S | 0.75 | 750 | 0.4415 | 900*900*780 900*900*930 900*900*1080 | 1-3 |
SC-1000-1S SC-1000-2S SC-1000-3S | 0.75 | 950 | 0.7084 | 1160*1160*880 1160*1160*1030 1160*1160*1180 | 1-3 |
SC-1200-1S SC-1200-2S SC-1200-3S | 1.5/2.2 | 1150 | 1.0380 | 1360*1360*980 1360*1360*1160 1360*1360*1360 | 1-3 |
SC-1500-1S SC-1500-2S SC-1500-3S | 1.5/2.2 | 1450 | 1.6500 | 1850*1850*1130 1850*1850*1330 1850*1850*1550 | 1-3 |
SC-1800-1S SC-1800-2S SC-1800-3S | 2.2 | 1750 | 2.4041 | 1-3 |
Application
l: Chemical industry: resin, pigment, cosmetic, coatings, Chinese medicine powder
lI: Food industry: sugar powder, starch, salt, rice noodle, milk powder, egg powder, sauce, syrup
lII: Metallurgy, Mine industry: aluminum powered, copper powder, ore alloy powder, welding rod powder.
lV: Medicinal industry: all kinds of medicine
V: Waste treatment: disposed oil, disposed water, disposed dye waste water, active carbon
lI: Food industry: sugar powder, starch, salt, rice noodle, milk powder, egg powder, sauce, syrup
lII: Metallurgy, Mine industry: aluminum powered, copper powder, ore alloy powder, welding rod powder.
lV: Medicinal industry: all kinds of medicine
V: Waste treatment: disposed oil, disposed water, disposed dye waste water, active carbon
About Us
Xinxiang Yuecheng Machinery Co., LTD is a standardized enterprise, specializing in kinds of vibrating screen equipment.
Our main products are three dimensional vibration sieve, linear vibrating screen, ultrasonic vibrating screen,
Tumbler sieve,airflow sieve high frequency sieve, sieve, strokes, mud testing screen, vibration motor, conveyor and other
mechanical equipment vibration.
In addition to the conventional series of products, but also provide customers with personalized products and equipment type selection service, widely used in food, medicine, chemical industry, resin, ceramic, metal powder mining and metallurgy, paper-making, ore processing and other industries
Our main products are three dimensional vibration sieve, linear vibrating screen, ultrasonic vibrating screen,
Tumbler sieve,airflow sieve high frequency sieve, sieve, strokes, mud testing screen, vibration motor, conveyor and other
mechanical equipment vibration.
In addition to the conventional series of products, but also provide customers with personalized products and equipment type selection service, widely used in food, medicine, chemical industry, resin, ceramic, metal powder mining and metallurgy, paper-making, ore processing and other industries
Please show us the following answers ,so that we can direct make a quoation for you .
Your company details contact infomation .such as email address ,and phone No.
1. Screen Material ?
2.Layers?
3. Mesh size each layer?
4. Capacity : _______KG/H
5. Moisture ,viscous ,corrosive.....
6. Voltage: _______V, ______HZ,3 phase.
7. Carbon Steel ,SS304.SS316...
Your company details contact infomation .such as email address ,and phone No.
1. Screen Material ?
2.Layers?
3. Mesh size each layer?
4. Capacity : _______KG/H
5. Moisture ,viscous ,corrosive.....
6. Voltage: _______V, ______HZ,3 phase.
7. Carbon Steel ,SS304.SS316...
