Product Overview

Description

please note:

Default with 1pcs 1310nm A side Fiber module and 1pcs 1550nmB side, 2pcs 1550nm B Side or 2pcs 1310nm A side can be provided as request.

Other selection please leave us a message about your requirements.

Fast Ethernet Switch 10/100/1000Base-Tx to 1000Base-FX Fiber Switch
The Fast Ethernet Switch  is an Ethernet Fiber Switch which is specially designed for network monitoring. It
has 2*10/100/1000Mbps Ethernet ports and 2*1.25G fiber ports. It adopts RTL8309N chips to ensure
low power consumption and high stability. It extends the transmission distance of a network from
100m to 120km via copper cables. It can extend the transmission distance; there are also many other
advantages such as isolation protection, good data security, working stability and easy maintenance.
Main Features:
1.Support the switch between 10/100/1000Base-TX and 100Base-FX
2.6*1.25G full-duplex fiber ports and 2*1000M Ethernet ports with auto-negotiation function
3.Support 100M speed rate, MDI/MDIX and half/full-duplex with auto-negotiation function
4.Each port has the complete LED Indicator light
5.Support single mode single fiber,single mode dual fiber ,multi-mode dual fiber and SFP slot
6.Support IEEE802.1d Spanning Tree
7.Support high performance QoS function on each port
8.Support 5V voltage input
9.Support IEEE 802.3x flow control and back pressure control
10.Require no configuration and will instantly operate as soon as you power it up
11.Low power consumption chip with heat sink built in to ensure longtime efficient operation

Specifications
Standards	IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX IEEE802.3x Flow control IEEE802.1p QoS IEEE802.1d Spanning Tree
Ethernet Port	Connector: RJ45 Data Rate: 10/100M Distance: 100m UTP Type: UTP-5E or higher level
Fiber Port	Connector: SC   Data Rate: 1.25G   Optical Wavelength: 850nm/1310nm/1490nm/1550nm   Distance: 25km
Performance	Processing Type: Store and Forward MAC Table Size: 8K Buffer Space: 1Mbit   Jumbo Packet: 1518 bytes Back bandwidth: 5.6G Time Delay: <150μs
Power	Power type: external power supply Input Voltage: AC100V~240V 50/60Hz Connector: DC Socket Working Voltage: 5V Power Consumption: 1.5W~2.5W
Transmissin Distance	Twisted Pair: 100m (CAT5e, CAT6 cables)    Single-mode: 40km
MTBF	100, 000 hours
Warranty	1 year
Environment	Storage Temperature: -40~70℃ Operating Temperature: -10~55℃ Relative Humidity: 5-90% ( no condensation)
Mechanical Structures	Dimension: 215×107×26mm Weight: 0.6KG
OEM&ODM	Supportive
