ANTISHICNC GHS4235 CNC Saw Machines Automatic Band Saw Machine Metal Cutting 350mm Fully Automatic Feed Factory Best Price
- Category: >>>
- Supplier: Shanghai Ants Machine Equipment Co. Ltd.
Share on (1600832869306):
Product Overview
Description
ANTISHICNC GHS4235 CNC Saw Machines Automatic Band Saw Machine Metal Cutting 350mm Fully Automatic Feed Factory Best Price
Technical Specifications| Model | GHS4235 |
Max. cutting size(mm) | 350*350 |
Saw blade speed (m/min) | 27/45/69 |
Saw blade specifications(mm) | 4115*34*1.1 |
Feed rate | CVT |
Main motor power | 3kw |
Hydraulic motor power | 0.75kw |
Water pump motor power | 0.04kw |
Clamping method (Vice) | Fully automatic |
Transfer method | Turbine shaft |
Package Size | 2220*2200*1850mm |
Weight | 1.5T |
ANTISHICNC GHS4235 CNC Saw Machines Automatic Band Saw Machine Metal Cutting 350mm Fully Automatic Feed Factory Best Price Product Details
The GHS Series PLC Controlled Fully Automatic Metal Cutting Band Saw is a rugged, modern shop saw for precise cuts in medium diameters. All operating switches are clearly grouped on the touch screen and control panel. The machine is mainly characterized by fully automatic control. Using PLC touch screen panel, you can adjust the feed of the saw frame, steplessly adjust the speed of the saw blade, and hydraulically process the workpiece. The powerful automatic feed does not require any electronics or programming and still provides high repeatability and dimensional accuracy.
The GHS Series Band Saws are designed for straight-line cutting of large workpieces made of steel, cast iron and other metals with a rigid double post frame for stability.
The GHS Series Band Saws are designed for straight-line cutting of large workpieces made of steel, cast iron and other metals with a rigid double post frame for stability.
ANTISHICNC GHS4235 CNC Saw Machines Automatic Band Saw Machine Metal Cutting 350mm Fully Automatic Feed Factory Best Price Standard Equipments
1. Sawing machine
2. Saw blade *1
3. Clamping of hydraulic parts
4. Cooling system
5. Work lights
6. Material rack
7. Operating tools
8. Operation Manual\t
2. Saw blade *1
3. Clamping of hydraulic parts
4. Cooling system
5. Work lights
6. Material rack
7. Operating tools
8. Operation Manual\t
1. Inverter
2. Electric chip removal
3. Power failure protection
4. Saw band hydraulic tensioning
5. Non-electric feeding frame 2 meters
6. Electric feeding frame 2 meters
7.PLC (Japan Omron & Schneider Electric)
Company Profile
ANTS Machine is a leading Chinese industrial lathe machinery andtooling machines supplier, located in the downtown of Shanghai City.Since our company was founded, based on the advantage of BOCHI which is the No.1 Chinese machine tool manufacturer, we continuallyintroduce top Chinese lathe machinery enterprises and their productsto international markets and export them to approximately 30countries and several regions across the globe, such as BOCHI,Shanghai Machine Tool, SPARK etc. Today we stand tallamidst a number of competitors across the world.
