Factory Sale Worklife longer 395nm UV LED printing curing lamp with UV lamp industry curer
- Category: >>>
- Supplier: Shenzhen Height-Led Opto-Electronics Technology Co. Ltd.
Share on (1600835406887):
Product Overview
Description
Product Description
Specification
Brand | Height-LED |
Model | XYUV-4II-FS300200-BH |
Controller size | L384mm*W284mm*H100mm |
Dimension of UV LED lamp | L380mm*W245mm*H110mm |
Curing area | 300X200mm |
Wavelength | 365/385/395/405nm （Optional） |
Optical intensity | 365/385nm 0.8W/cm2 |
395/405nm 1.2W/cm2 | |
Lamp beads | Imported LED lamp beads |
Lamp beads life | ≥20000H |
Cooling method | Fan cooling |
Control style | MCU+HMI |
Parameter setting | Touch screen operation +RS485 Rmote operation |
Power adjustment | Digital dimming（1-100%） |
Voltage | AC100-AC240V(50/60HZ) |
Total power consumption | 1100W |
Net weight | 18KG |
Ambient temperature | -10℃-50°℃ |
Relative humidity | 25%-80%RH |
Packing & Delivery
FAQ
Q1: Why choose Height-LED UV LED curing system?
A: The team has over 10 years combined experience in UV LED curing industry and can meet the requirements of each client.
Q2: What's the application of Height-LED UV LED curing system?
A: Height-LED UV LED curing system can be used for curing UV glue, UV ink, UV adhesive,UV paint,UV varnish and other UV sensitive materials.
Q3: What is the major advantages of UV LED curing system than other UV curing system?
A: Extra-long life, energy saving and environment friendly.
Q8: Where is your company located?
A: The team has over 10 years combined experience in UV LED curing industry and can meet the requirements of each client.
Q2: What's the application of Height-LED UV LED curing system?
A: Height-LED UV LED curing system can be used for curing UV glue, UV ink, UV adhesive,UV paint,UV varnish and other UV sensitive materials.
Q3: What is the major advantages of UV LED curing system than other UV curing system?
A: Extra-long life, energy saving and environment friendly.
Q4: Which wavelength do I need?
A: It depends on your UV sensitive materials.
Q5: What's the emitting window do I need?
A: It depends on your product's size that need to be cure.
Q6: What's the Peak Irradiance do I need?
A: It depends on your UV sensitive materials and your Production efficiency.
Q7:The common emitting window and Peak Irradiance can not meet my requirements?
A:Do not worry! Any sizes of emitting window and Peak Irradiance can be customized.
Q8: Where is your company located?
A:2/F,Towel B, Sanhe international science and technology Building, Da Lang Road,Long Hua District, ShenZhen, Guang Dong Province, China.
Q9: What's the price?
A: Kindly make a request and tell us your curing area.
A: Kindly make a request and tell us your curing area.
