item | value |
Model | Dell PowerEdge R350 |
Processor | One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 core |
Memory | Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s • Supports unregistered ECC DDR4 DIMMs only NOTE: For Pentium processor, maximum memory speed supported is 2666 MT/s |
Storage controllers | Internal controllers (RAID): PERC H355, PERC H355f, PERC H345, PERC H345f, H755, H755f, HBA355i, HBA355f, S150 • Internal Boot: Internal Dual SD Module or USB or Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs • External HBAs (non-RAID): HBA355e |
Drive Bays | Front bays: • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 128 TB |
Power Supplies | • 600W Platinum 100-240 VAC or 240 VDC redundant, hot swap |
Dimensions | • Height – 42.8 mm (1.69 inches) • Width – 482 mm (18.98 inches) • Depth – 585.3 mm (23.04 inches) without bezel 598.94 mm (23.58 inches) with bezel |
Fans | Up to four fans with full redundancy |
Dimensions | • Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 758.3 mm (29.85 inches) - without bezel 772.14 mm(30.39 inches) - with bezel |
Form Factor | 1U rack server |
Embedded Management | iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module |
Embedded NIC | 2 x 1 GbE LOM |
Ports | Front Ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 2.0 |
PCIe | 3 PCIe slots: • 1x8 Gen4 (x16 connector) low profile, half length • 1x8 Gen4 (x8 connector) low profile, half length • 1x4 Gen4 (x8 connector) for dedicated PERC only |
