Model | Voltage (V) | Capacity (AH) | Weight (KG) | Dimensions(L×W×H,mm) | Terminal | |||||
SRM2.2 | 12V | 2.2 | 0.82 | 178x34x60 | 12.8V | |||||
SRM3.3 | 12V | 3.3 | 1.4 | 134x67x60 | F1 | |||||
SRM4 | 12V | 4 | 1.45 | 90x70x101 | F1 | |||||
SRM7 | 12V | 7 | 2.3 | 151x66x98 | F1 | |||||
SRM12 | 12V | 12 | 3.5 | 151x98x95 | F2 | |||||
SRM17 | 12V | 17 | 5.6 | 181x76x167 | F2 | |||||
SRM20 | 12V | 20 | 6.5 | 181x76x167 | L | |||||
SRM24 | 12V | 24 | 8 | 175x165x125 | M5 | |||||
SRM33 | 12V | 33 | 10 | 196x130x174 | L | |||||
SRM40 | 12V | 40 | 12 | 197x165x175 | M5 | |||||
SRM55 | 12V | 55 | 16 | 228x137x207 | M6 | |||||
SRM65 | 12V | 65 | 19.5 | 350x166x175 | M6 | |||||
SRM75 | 12V | 75 | 21.5 | 260x168x210 | M8 | |||||
SRM100 | 12V | 100 | 29 | 330x171x217 | M6 | |||||
SRM120 | 12V | 120 | 35.0 | 412x173x225 | M8 | |||||
SRM150 | 12V | 150 | 42 | 483x170x237 | M8 | |||||
SRM200 | 12V | 200 | 59 | 522x240x219 | M8 | |||||
SRM250 | 12V | 250 | 67 | 520x269x220 | M8 | |||||
SRM260 | 12V | 260 | 70 | 520x269x220 | M8 | |||||
Note:The company reserves the right to change the specifications of this datasheet without prior notice for improving product quality or upgrading relevant technical parameters. Please contact us for the latest product information. | ||||||||||
