Cheap Price Abb 10Kw Hybrid Solar Inverter With Wifi
- Category: >>>
- Supplier: Jiangsu Suyan Lighting Technology Co. Ltd.
Share on (1600836209129):
Product Overview
Description
Specification
Datasheet | SPH 7000TL3 BH | SPH 8000TL3 BH | SPH 10000TL3 BH |
Max. recommended PV power (for module STC) | 9100W | 10400W | 13000W |
Max. DC voltage | 1000 | 1000 | 1000 |
Start voltage | 160V | 160V | 160V |
MPP voltage range | 160V-1000V / 600V | 160V-1000V / 600V | 160V-1000V / 600V |
No. of MPP trackers | 2 | 2 | 2 |
No. of PV strings per MPP tracker | 1 | 1 | 1 |
Max. input current per MPP tracker | 12A | 12A | 12A |
Max. short-circuit current per MPP tracker | 15A | 15A | 15A |
AC nominal power | 7000W | 8000W | 10000W |
Max. AC apparent power | 7000VA | 8000VA | 10000VA |
Max. AC output power | 7000W | 8000W | 10000W |
Max. AC apparent power | 7000VA | 8000VA | 10000VA |
Max. output current | 10.6A | 12.1A | 15.2A |
MAX. efficiency | 98.2% | 98.2% | 98.2% |
European efficiency | 97.4% | 97.4% | 97.5% |
Dimensions (W / H / D) | 505/453/198mm | 505/453/198mm | 505/453/198mm |
Weight | 28kg | 28kg | 28kg |
Operating temperature range | –25 °C ... +60 °C | –25 °C ... +60 °C | –25 °C ... +60 °C |
Nighttime power consumption | < 13W | < 13W | < 13W |
Topology | Transformerless | Transformerless | Transformerless |
Cooling | Natural | Natural | Natural |
Protection degree | IP65 | IP65 | IP65 |
Relative humidity | 0~100% | 0~100% | 0~100% |
Product Description
Company Profile
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q: How could I get a sample?
A: Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.
Q: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
A: Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.
Q: Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q: Whether you could make your products by our color?
A: Yes, The color of products can be customized if you can meet our MOQ.
Q: How to guarantee the quality of your products?
A: 1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
