150W Series | ||||
Input | Input Voltage | 90-264Vac | ||
Frequency | 50/60Hz | |||
Input AC Current | 2.5A MAX | |||
Output | Output Voltage | 5.0-48Vdc | ||
Output Amp | 0.1-12.0A | |||
Power | 150W MAX | |||
AC PLUG | C6,C8,C14 | |||
DC cable | 2464/2468/1185 Cable /L=1.2m/ 1.5M/1.8M (OEM available ) | |||
DC plug | 6.3*2.5/5.5*2.5/5.5*2.1/4.0*1.7/3.5*1.35/2.5*0.7 or Customization | |||
Color | Black / White or Customization | |||
Main Features | SCP/OVP/OCP | |||
Environmental | Operating temperature | 0~40℃ | ||
Storage temperature | -20℃ to +80℃ | |||
Humidity | 5% to 95% Non-Condensing | |||
Safty | Ul/CE/GS/FCC/EMC/SAA/CCC/PSE/KC/BIS/ROHS/REACH | |||
Standard | IEC62368/60950/60065/61558/1310/61347/60601 | |||
Energy Efficiency | ERP/CEC/DOE/NRcan/GEMS level VI | |||
