10L Lab Horizontal rectification column with electromagnetic reflux ratio funnel
- Category: >>>
- Supplier: Shanghai Yuhua Instrument Equipment Co. Ltd.
Share on (1600837463655):
Product Overview
Description
Product display
Specification
Model RFJL-10L | ||||||||
NO. | Name | Specification | Quantity | Explain | ||||
1 | Thermometric sleeve | 1 piece | Connect the tower tank temperature measuring port, tower tank, tower temperature measurement | |||||
2 | Glass cock switch | 24# | 2 piece | feed | ||||
3 | Precision distillation column | Ф35x1000mm | 1 section | The upper and lower mouth is 24# standard grinding (can also be made on request) with electric heating wire | ||||
4 | Heater | 1 piece | Matching distillation column using controller, digital display temperature | |||||
5 | Precision rectifying head | Matching with equipment | 1 piece | Electromagnet automatic control of reflux ratio snaking tube condenser, steam inlet, tower top gas phase temperature measuring port, discharge port | ||||
6 | Fraction receiver | 2000ml | 1 piece | Fraction acceptance | ||||
7 | Secondary condenser | diameter 30*400MM | 1 piece | Optional | ||||
8 | Glass cock switch | 24# | 1 piece | Replace the receiving bottle under vacuum | ||||
9 | Reflux ratio controller | KLTC-1F | 1 set | Power cord included | ||||
10 | Packing | 1 set | Glass spring packing | |||||
11 | Electromagnet | 36V | 1 piece | Used to control reflux and recovery | ||||
12 | Heating device | 10000ML | 1 set | ZNCL-TS 10L Magnetic stirring electric heating sleeve | ||||
13 | Mounting bracket | 1 set | Stainless steel frame | |||||
14 | Instrument clamp | several | Including universal clip, cross clip | |||||
15 | Vacuum tube | 3m | Vacuum pipe connection | |||||
16 | Vacuum silicon ester | 1 box | Vacuum seal | |||||
