Microsensor MPM483E LCD LED Display Low Cost Analog Output Pressure Transmitter for Equipment
- Category: >>>
- Supplier: Micro Sensor Co. Ltd.
Share on (1600837878302):
Product Overview
Description
Product Description
MPM483E Pressure Transmitter is a cost-effective, universal digital pressure transmitter product launched by our company, the product adopts high-stability diffusion silicon pressure core and advanced digital conditioning circuit, combined with mature pressure transmitter design and manufacturing technology, to ensure the accuracy and stability of pressure measurement. The product adopts corrosion-resistant 2088 shell head, which can be applied to relatively severe working conditions; High-brightness LED and backlit LCD display, suitable for places that require on-site inspection; The product as a whole has passed a higher level of electromagnetic compatibility test and can be used for equipment or environments with electromagnetic interference.
Specification
item | value |
Product Model | MPM483E |
Range | -1bar…0mbar ~ 100mbar…1000bar |
Over pressure | ≤ 2×FS or 1100bar (whichever is less) |
Pressure Type | gauge, absolute, sealed gauge |
Accuracy | ±0.25%FS, ±0.5%FS, ±1.0%FS |
Long-term Stability | ±0.3%FS/year |
Operation Temperature | -30℃ ~ 80℃ (General type) -20℃ ~ 60℃ (with LCD display) -30℃ ~ 70℃ (with LED display) |
Storage Temperature | -40℃ ~ 120℃ |
Vibration | 10g, 55Hz ~ 2000Hz |
Impact | 100g, 11ms |
Protection Degree | IP65 |
Weight | ≤375g |
FAQ
Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer since 1971 on Pressure/ Level/ Temperature/ Flow transmitters with 4~20mA, Hart, Rs485 &
Modbus protocols, pressure sensors with SDI, I2C, 4~20mA, 0.5~4.5V and etc, and wireless IOT measurement transmitters. We provide
high-quality products with high competitive factory prices.
Q: What's your quality control system?
A: As an ISO9001:2008 certificated manufacturer, we have a strict quality control system, and each product is done with fatigue
testing, calibration, temperature compensation before shipment. High quality is guaranteed.
Q: Is there MOQ with your product?
A: MOQ is 5, 1pc for testing is acceptable.
Q: Do you provide customized products?
A: Yes, we can print your logo on our products; OEM, ODM & customization are welcomed.
Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 12 months after shipment, and our after-sales will respond with your questions in 24hrs, remote
instruction by PC network is always available.
Q: What is the lead time of your product?
A: We are a factory, our lead time is always within 10~15 working days for products without customization, but lead-time will vary
based on different products. You can check detailed lead-time with our sales.
Q: What international certificates do you have for your products?
A: We have CE, RoHS, UL, ATEX as well as ship-use DNV, etc.
A: We are a professional manufacturer since 1971 on Pressure/ Level/ Temperature/ Flow transmitters with 4~20mA, Hart, Rs485 &
Modbus protocols, pressure sensors with SDI, I2C, 4~20mA, 0.5~4.5V and etc, and wireless IOT measurement transmitters. We provide
high-quality products with high competitive factory prices.
Q: What's your quality control system?
A: As an ISO9001:2008 certificated manufacturer, we have a strict quality control system, and each product is done with fatigue
testing, calibration, temperature compensation before shipment. High quality is guaranteed.
Q: Is there MOQ with your product?
A: MOQ is 5, 1pc for testing is acceptable.
Q: Do you provide customized products?
A: Yes, we can print your logo on our products; OEM, ODM & customization are welcomed.
Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 12 months after shipment, and our after-sales will respond with your questions in 24hrs, remote
instruction by PC network is always available.
Q: What is the lead time of your product?
A: We are a factory, our lead time is always within 10~15 working days for products without customization, but lead-time will vary
based on different products. You can check detailed lead-time with our sales.
Q: What international certificates do you have for your products?
A: We have CE, RoHS, UL, ATEX as well as ship-use DNV, etc.
