1. Simple operation, easy to learn and use.
2. Easy loading and fast unloading
3. Equipment mixing evenly, strong power, high mixing efficiency.
4. Rational structure design and convenient maintenance.
5. Suitable for solid, liquid, concrete and sand;Mortar;Feed;Fertilizer and other materials stir.



Specification for TL3500 Self-loading Concrete Mixer Truck | ||||
Drum | Drum capacity | 2.5cbm | ||
With drum lifting | ||||
Real concrete yield per batch | 2.5cbm | |||
Weight system | Made in China | |||
Productivity | BATCH≤15MINS, 4BATCHS/10m³ | |||
Transmission | Hydraulic | |||
4 wheel driver,2 wheel steering | ||||
Tyre size | Front(double tires) | 16/70-20 | ||
Rear | 16/70-20 | |||
Water Tank | 620L | |||
Engine | Yunnei | |||
Model | FOUR-CYLINDER 2400RPM | |||
Diesel Water-cooled | ||||
76kw | ||||
Speed Range | Low:7.5KM/H | |||
Middle:0-18KM/H | ||||
High: 40KM/H | ||||
Discharge | 270° discharging | |||
TIPPING CHUTE | Equipped with 2 chute for detachable to increase discharging length | |||
Weight | 7500kg | |||
Overall dimension(L*W*H) | 4370 x 2700 x 3910mm | |||
