BIOBASE China Gas Chromatograph with LCD display in stock for sale for lab for hospital can connect with internat

Share on:

Price in USD:Details


Product Overview


BIOBASE Gas Chromatograph Analyzer
*1 Year Free Warranty
*Life Time Technical Service
* Video /Call Suggestion within 6 hours

Product Introduction

BIOBASE BK-GC7820 Gas Chromatograph Analyzer
BIOBASE BK-GC7820 Gas Chromatograph Analyzer

1. 5.7-inch LCD display indicates temperature,time andgas flow.
2. Self-test, power protection, keyboard lock, automatic ignition andantipower mutation interference function.
3. Can connect with Internet,realize data transfer and program upgrade automatically.
4. Equipped with a flame ionization detector (FID), and TCD, ECD, FPD, NPD are optional. Can install3 detectors at the same time.
5. Can install packed column and capillary column at the same time
6. Double column compensation function,which can effectively restrain baseline drift and theinfluence of background noise.
7. Large capacity oven (300*280*180mm) can hold 2 pcs 0.32mm diametercapillary column (length: 80m).

Technical Parameter

Temp. Range
Temp. Accuracy
Temp. Program
Max. Temp. Heating Rate
Hydrogen Flame Ionization Detector (FID)
Detection limit:≤3×10-12g/s
Baseline drift:≤1x10-13A/30min
Linear range:≥107
ThermalConductivityDetector (TCD) (Optional)
Sensitivity: >
(Sample: n-hexadecane)
Linear range:≥105
Electron Capture Detector (ECD) (Optional)
Detection limit:≤1×10-14g/ml
(Sample:n-hexadecane δ-666)
Linear range: ≥104
Flame Photometric Detector (FPD) (Optional)
Detection limit:≤2×10-11g/s(S ofthiophene)
Detection limit:≤1×10-12g/s(P ofmethyl parathion)
Linear range (S): ≥103
Linear range (P): ≥104
Nitrogen and Phosphorus Detector (NPD) (Optional)
Detection limit:≤1×10-12g/s(Azobenzene)
Detection limit:≤1×10-12g/s(Marla sulfur phosphorous)
Linear range: ≥103
Power Supply
AC110/220V±10%, 50/60Hz
Standard Accessory
FID detector, Chromatography workstation software
Optional Accessory
Sample injection system, TCD, ECD, FPD and NPD detector, Chromatographic column.
Package Size (W*D*H)
Gross Weight
