Best Price ODM 4K Android OPS Interactive Display Smart board 55 Inch Touch Screen Interactive Board
- Category: >>>
- Supplier: Guangzhou Shuyong Intelligent Technology Co. Ltd.
Share on (1600845018518):
Product Overview
Description
Best Price ODM 4K Android OPS Interactive Display Smart board 55 Inch Touch Screen Interactive Board
Interactive touch screen whiteboard
Our touch screen whiteboard harnesses state of the art technology creating an impressive, multi-use digital screen display. The Ultra HD display delivers incredible image quality with four times higher resolution than Full HD. Optimised for viewing distance both near and far the display allows your content to take center stage for all your visual communication.
These screens are interactive and feature 20 touch points which means you can collaborate with your team around the screen and 20 users can be interacting with the screen at any one time.
Alongside the touch function, the screen also features a whiteboard which comes with a smart pen stylus. Write directly onto the screen and save your annotations to your computer seamlessly.
Product Description
Product Parameter
display | Screen size | 55 inch |
Backlight type | DLED direct type | |
display type | 2D | |
dot pitch | 0.372 x 0.372mm | |
effective display area | 1208*677MM | |
screen ratio | 16:9 | |
physical resolution | 1920*1080 FHD | |
brightness | 250-300cd/㎡ (center point) | |
Contrast | 1400:1 (Typ.) Transmission | |
display color | 8 bits/16.7 Million | |
Viewing angle | 178°,178° | |
refresh rate | 60Hz | |
corresponding time | 8ms | |
Sound output power | 8Ω8W x2 | |
touch | touch type | Infrared touch screen |
touch points | 20 touch points | |
touch-embedded | Edge embedded | |
touch drive | HID free drive | |
Touch writing surface material | 3mm tempered glass | |
Touch screen sensing method | Fingers or other non-transparent touch-sensitive media | |
Touch screen positioning resolution | 4096X4096 | |
Touch system communication port | USB 2.0 | |
Detection function and calibration | With software automatic detection function | |
responding speed | <8ms | |
touches | unlimited | |
Scan speed | 100Hz/sec | |
Cursor speed | 125P/S | |
touch accuracy | ≦2mm | |
Installation and maintenance method | Rear\\side disassembly maintenance type | |
Touch Support OS | XP/Win7/ Win10/ LINUX/ Android |
Overall size | 1257.7*745.2*82.2MM | No external installation medium | ||||
Including hanger size | 1257.7*745.2*103.5MM | Hanger hole distance: | 400*400MM | |||
Wall Mounting Dimensions | 1277.7*765.2*103.5MM | Installation principle: | Increase 20mm on one side | |||
Package dimensions | 1366.6*185*891.5mm | Packing: | Kraft carton | |||
Net weight/gross weight | 23.5/30.5KG | Net weight (bare metal weight)/gross weight (including accessories and packaging) | ||||
Installation method | Hanger (standard) | |||||
Front interface | USB1 (OPS input), USB2 (TV board input) | |||||
storage environment | Storage temperature: -20℃~60℃; Storage humidity: 10%RH~90%RH | |||||
working environment | Working temperature: -10℃~55℃; Working humidity: 10%RH~90%RH | |||||
service life | ≧50000 hours | |||||
Operating Voltage | 110~240V/50~60Hz | Power Switch/Location | yes/rear | |||
Power consumption | about 120 watts | Power Type/Method | Three-core power supply/fixed | |||
Standby power consumption | ≦0.5W | Power Interface Specifications | Pin seat | |||
Applications
Best Selling
Our Company
Guangzhou Shuyong Intelligent Technology Co., Ltd. was established in 2013. Through our accumulated experience, stable quality control system, and continuous R&D investment, we provide governments, schools, public transportation, retail and shopping malls,supermarkets, hotels, and banks in the global market. Diversified solutions.
SYET has obtained CE, KCC, FCC, CCC, ROHS, IC,SASO,PSE certifications
As an ISO9001 certified manufacturer, we have become a reliable world-class ODM/OEM partner in the market, while
SYET also offers its own design and branded products with the ability to cut LCD displays, optical lamination processes and smart board backlight modules custom made. SYET has won the favor of many customers from abroad.
SYET main Partners: Coca Cola,Pepsi, KYOCERA Corporation, Huawei, Midea, Chinese Academy of Sciences, Hollywood, Heng Dian World Studios etc. Looking forward to working with you.
FAQ
1)Are you a factory or trading company ?What is the MOQ?
A:Yes, we are factory direct sales and have some items in stock , youcan order 1pcs for test.
2) What is the delivery time? Where do you ship ?
A:Generally speaking , the goods can be delivered within 5-7 days for small orders, and the production time about 15 days for more than 10pcs. In addition, our factory is located in PanYu, GuangZhou. If you have forwarder in Shenzhen or Guangzhou, we can help shipment to your fowarder .
3) Could you provide OEM&ODM service?
A:of course , including software, packaging, product logo, etc., consult customer service for more details.
4) What is the warranty period of the product?
A:Normally it is 1 year, we have a professional after-sales service team,specific details can consult customer service.
5)How do you guarantee the quality of your products?
A:Our products comply with ISO9001 quality system and CE/FCC/ROHS standards. All our products pass strict QC inspection in the production process. In particular, export products need to complete 72-hour aging test to ensure no problems before shipment.
6)How do you arrange transportation?
A:If small sample orders suggest express delivery (7-10 days) or air freight (10-15 days), if bulk production advise by sea more favorable , please consult customer service for more details !
