Model | WHL-25A/WHL-25AB | WP-25A/WP-25AB | |||
Cycle Mode | Natural convection | ||||
Function | Temp.Range | RT+10-300C | RT+5-65°C | ||
Temp. Resolution Ratio | 0.1C | ||||
Temp. Motion | +1C | +0.5%C | |||
Temp. Uniformity | 土3.5% | +2.0C | |||
Structure | Inner Chamber | B model: mirror stainless steel; without B model: High strength galvanized sheet | |||
Outer Shell | cold rolling steel electrostatic spraying exterior | ||||
Insulation Layer | High quality rock wool board(with CE) | ||||
Heater | Nickel chromium alloy heating wire | ||||
Power Rating | 0.6kW | 0.18kW | |||
Exhaust Hole | φ28mm top (with function of test hole) | ||||
Controller | Temp. Control Mode | Two temperature section intelligent PID | |||
Temp. Set Mode | Touch button setting | ||||
Temp. Display Mode | Measuring temperature: display on the four digital tubes upper row ; setting temperature:display on the lower row | ||||
Timer | 0-9999min(with timing wait function) | ||||
Operation Function | fixed temperature operation, timing function, auto stop | ||||
Additional Function | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking. power-off parameter memory | ||||
Sensor | PT100 | ||||
Safety Device | over temperature sound-light alarm | ||||
Specification | Inner Chamber Size(W~L“H)(mm) | 260*260*260 | |||
Exterior Size(WL*H)(mm) | 380*455*568 | ||||
Packing Size(WLH)(mm) | 500*530*657 | ||||
Volume | 18L | ||||
Shelf Number | 6 | ||||
Load Per Rack | 15kg | ||||
Shelf Space | 29mm | ||||
(50/60HZ)Current Rating | AC220V/2.7A | AC220V/0.8A | |||
NW/GW (kg) | 27/35 | ||||
Accessory | Shelf | 2 | |||
Optional Accessories | Shelf,Programmable controller | ||||
