dell poweredge server r750 dell server for 2u rack server
- Category: >>>
- Supplier: Beijing Jingda Shengye Technology Co. Ltd.
Share on (1600854155014):
Product Overview
Description
Dell EMC PowerEdge R750 | ||
Features | technical specifications | |
processor | Supports up to two 3rd generation Intel Xeon scalable processors (up to 40 cores per processor) | |
RAM | •32 DDR4 DIMM sockets supporting a maximum RDIMM of 2 TB or a maximum LRDIMM of 8 TB at speeds up to 3200 MT/s • Up to 16 Intel Permanent Memory 200 Series (BPS) slots, up to 8 TB • Only registered ECC DDR4 DIMMs are supported | |
Storage controller | • Internal controller: PERC H745, HBA355I, S150, H345, H755, H755N • Boot optimized storage subsystem (BOSS-S2): HW RAID 2 x M.2 SSD 240 GB or 480 GB • External PERC (RAID): PERC H840, HBA355E | |
Drive Bay | Front tray: • Up to 12 x 3.5 inch SAS/SATA (HDD/SSD), up to 192 TB • Up to 8 x 2.5 inch NVMe (SSD), up to 122.88 TB • Up to 16 x 2.5 inch SAS/SATA/NVMe (HDD/SSD), up to 245.76 TB • Up to 24 x 2.5 inch SAS/SATA/NVMe (HDD/SSD), up to 368.84 TB Rear rack: • Up to 2 x 2.5 inch SAS/SATA/NVMe (HDD/SSD), up to 30.72 TB • Up to 4 x 2.5 inch SAS/SATA/NVMe (HDD/SSD), up to 61.44 TB | |
Power Supply | • 800 W platinum AC/240 HVDC • 1100 W titanium AC/240 HVDC • 1400 W Platinum AC/240 HVDC • 2400 W platinum AC/240 HVDC | |
Fan | • Standard fan/high-performance SLVR fan/high-performance gold medal fan • Up to six hot swappable fans | |
size | • Height - 86.8 mm (3.41 in) • Width - 482 mm (18.97 in) • Thickness - 758.3 mm (29.85 in) - without bezel 772.14 mm (30.39 in) - with bezel | |
Outline specification | Outline specification 2U rack server | |
Embedded management | • iDRAC9 • iDRAC Service Module • iDRAC Direct • Quick Sync 2 Wireless Module | |
Embedded NIC | 2 x 1 GbE LOM | |
GPU options | Up to two double width 300 W, or four single width 150 W or six single width 75 W accelerators | |
port | Front end port • 1 dedicated iDRAC Direct micro USB • 1 USB 2.0 • 1 VGA Back port • 1 USB 2.0 • 1 serial (optional) • 1 USB 3.0 • 2 RJ-45 • 1 VGA (optional for liquid cooling configuration) Internal port • 1 USB 3.0 | |
PCIe | Up to 8 x PCIe 4.0 slots (up to 6 x16), supporting snapshot I/O modules | |
Operating system and hypervisor | • Canonical Ubuntu Server LTS • Citrix Hypervisor • 带 Hyper-V 的 Microsoft Windows Server • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMWare ESXi | |
