  • 24 port Gigabit power 4 Gigabit fiber port two layer WEB enterprise network switch H3C S5024PV5 EI HPWR
24 port Gigabit power 4 Gigabit fiber port two layer WEB enterprise network switch H3C S5024PV5 EI HPWR
24-port Gigabit power + 4 Gigabit fiber port two-layer WEB enterprise network switch H3C S5024PV5-EI-HPWR

24 port Gigabit power 4 Gigabit fiber port two layer WEB enterprise network switch H3C S5024PV5 EI HPWR

Share on (1600862449005):


Price:$365.00

Quantity:


Product Overview

Description



Products Description


H3C S5000PV5-EI
H3C S5000V5-EI series is the latest development of Gigabit speed managed Ethernet switch that is especially for SMB (Small Business) market. Besides high-performance access, it also offers abundant security access policy control and enhanced network manageability and maintenance. This makes it ideal for network construction on industries such as government, small to midsize enterprise, school and hotel.
H3C S5000V5-EI series Ethernet switch includes the following models:
S5008PV5-EI-S: 8*10/100/1000BASE-T Ports and 2*1000BASE-X SFP Ports
S5016PV5-EI-S: 16*10/100/1000BASE-T Ports and 4*1000BASE-X SFP Ports
S5024PV5-EI-S: 24*10/100/1000BASE-T Ports and 2*1000BASE-X Ports
S5024PV5-EI: 24*10/100/1000BASE-T Ports and 4*1000BASE-X Ports
S5048PV5-EI: 48*10/100/1000BASE-T Ports and 4*1000BASE-X Ports
S5008PV5-EI-HPWR: 8*10/100/1000BASE-T PoE+ Ports and 2*1000BASE-X SFP Ports
S5016PV5-EI-PWR-S: 16*10/100/1000BASE-T PoE+ Ports and 2*1000BASE-X SFP Ports
S5024PV5-EI-PWR-S: 16*10/100/1000BASE-T PoE+ Ports, 8*10/100/1000BASE-T Ports and 2*1000BASE-X Ports
S5024PV5-EI-HPWR: 24*10/100/1000BASE-T PoE+ Ports (AC 370W) and 4*1000BASE-X SFP Ports
S5048PV5-EI-PWR: 48*10/100/1000BASE-T PoE+ Ports (AC 370W) and 4*1000BASE-X SFP Ports


Features
S1850V2-10P-PWR
S1850V2-10P-PWR-EI
S1850V2-28P-HPWR
S1850V2-28P-HPWR-EI
Switching capacity
192Gbps
192Gbps
240Gbps
256Gbps
Packet forwarding rate
30Mpps
42Mpps
78Mpps
78Mpps
Management port
1 console port
10/100/1000 Base-T port
8
8
24
24
SFP port
2
2
4
4
Copper port features
Half-duplex, full-duplex, auto-negotiation
MDI/MDI-X
Ethernet functions
Traffic control (802.3x)
Automatic port energy-saving
Dynamic link aggregation (802.3ad) and static port aggregation
802.1p and 802.1Q
Cable diagnosis
STP(802.1D)/RSTP(802.1w)/MSTP(802.1s)
TC snooping
BPDU protection/root protection/loopback protection/protection against TC-BPDU attack
IPv4
ARP
DHCP Client
Broadcast
IGMP V1/V2/V3 snooping
Fast leave function
QoS
Diff-Serv QoS
SP/WRR/SP+WRR
Traffic speed control
802.1p/DSCP priority mapping
Security
Hierarchical user management
Blackhole MAC
Limit of number of port MAC addresses to be learned
SSL
Network management and monitoring
Web page configuration
Uploading and downloading management of FTP, TFTP, and Xmodem files
System management
Uploading and downloading of FTP, TFTP, Xmodem, and SFTP files
SNMP V1/V2c/V3
NTP clock
System operating logs
Cluster management
Lightning protection level
6 kV
Environment temperature
Operating temperature：-5℃~45℃
Storage temperature：-40℃~70℃
Environment humidity
Operating humidity：5%~95% , non-condensing
Storage humidity：5%~95% , non-condensing
Power consumption
≤90W
≤90W
≤448W
≤448W
PoE+
65W
65W
370W
370W
Weight
≤3kg
<3kg
<4kg
≤4.5kg
Input voltage range
AC: 100V~240V AC，50/60Hz;
Dimensions (W × D x H)
330*230*44 mm
330*230*44 mm
440*260*44 mm
440*260*44 mm
