Product Overview
Description
AI Face Recognition People Counting 8MP Bullet Motorized vari-focal CCTV Camera IPC-HFW7842H-Z-S2 IPC-HFW7842H-Z4-S2
Products Description
8MP IR Bullet WizMind Network Camera
> 8-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Built-in IR LED, and the max. illumination distance is 60 m.
> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter
protection,etc.
>Supports P-Iris, the camera can control the iris more precisely for better image effect.
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card
error, network disconnection, IP conflict and illegal access.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card.
> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).
> IP67, IK10 protection grade.
> 12 VDC power output, max. current 165 mA , easy for installation
> Anti-corrosion coating(optional).
> 8-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Built-in IR LED, and the max. illumination distance is 60 m.
> With deep learning algorithm, it supports video metadata, face detection,face recognition,people counting, perimeter
protection,etc.
>Supports P-Iris, the camera can control the iris more precisely for better image effect.
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card
error, network disconnection, IP conflict and illegal access.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS485, BNC, supports max. 256 G Micro SD card.
> 12 VDC/24 VAC/PoE power supply (the power ports are different depending on the power supply).
> IP67, IK10 protection grade.
> 12 VDC power output, max. current 165 mA , easy for installation
> Anti-corrosion coating(optional).
Product Paramenters
Camera | ||
Image Sensor | 1/1.8" CMOS | |
Max. Resolution | 3840 (H) × 2160 (V) | |
ROM | 4 GB | |
RAM | 2 GB | |
Scanning System | Progressive | |
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | |
Min. Illumination | 0.003 lux@F1.2 (Color, 30 IRE) | |
0.0003 lux@F1.2 (B/W, 30 IRE) | ||
0 lux (Illuminator on) | ||
S/N Ratio | >56 dB | |
Illumination Distance | 60 m (196.85 ft) | |
Illuminator On/Off Control | Auto; manual; zoomprio | |
Illuminator Number | 4 (IR LED) | |
Lens | ||
Lens Type | Motorized vari-focal | |
Lens Mount | Module interface | |
Focal Length | 2.7-12 mm | |
Max. Aperture | F1.2 | |
Field of View | Horizontal: 112° (W)–47° (T) | |
Vertical: 58° (W)–26° (T) | ||
Diagonal: 137° (W)–54° (T) | ||
Iris Control | Auto; P-iris | |
Close Focus Distance | 1 m (3.28 ft) | |
DORI Distance | Lens | |
W | ||
T | ||
Smart Event | ||
IVS | Abandoned object; missing object | |
Professional, intelligent | ||
IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection | |
Face Detection | Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting | |
Face Recognition | Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (recognition priority and optimization snapshot); face angle filter; optimization time setting. Support 5 face databases; register one by one or in batches; support face recognition similarity settings and face comparison on the basis of 100,000 face databases. | |
People Counting | Tripwire people counting and people counting in area; generating and exporting report (day/month/year); queue management and exporting report (day/month); 4 rules can be set for tripwire, people counting in area and queue management. | |
Video Metadata | Motor vehicle, non-motor vehicle, face, human detection; track; snapshot; snapshot optimization; optimal face snapshot uploadMotor vehicle, non-motor vehicle, face, human detection; track; snapshot; snapshot optimization; optimal face snapshot upload. | |
Motor vehicle attributes: license plate, vehicle type, vehicle color, vehicle logo, seatbelt, smoking, calling,etc. | ||
Non-motor vehicle attributes: type, color, number of people, top type and color ,helmet. | ||
Human body attributes: top/bottom type and color, bag, hat, gender, and umbrella. | ||
Face attributes: gender, age, expressions, glasses, face mask and beard. | ||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | |
Video | ||
Video Compression | H.265; H.264; H.264H; MJPEG (Only supported by the sub stream) | |
Smart Codec | Smart H.265+; Smart H.264+ | |
Video Frame Rate | Main Stream: 3840 × 2160 (1–25/30 fps) | |
Sub stream: 704 × 576 (1–25 fps);704 × 480 (1–30 fps) | ||
Third stream: 1920 × 1080 (1–25/30 fps) | ||
Fourth stream: 1920 × 1080 (1–25/30 fps) | ||
Fifth stream: 704 × 576 (1–25fps);704 × 480 (1–30 fps) | ||
Stream Capability | 5 streams | |
Resolution | 3840 × 2160; 3072 × 2048; 3072 × 1728; 2592 × 1944; 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | |
Bit Rate Control | CBR/VBR | |
Video Bit Rate | H.264: 8 kbps–16384 kbps | |
H.265: 3 kbps–14050 kbps | ||
Day/Night | Auto (ICR)/Color/B/W | |
BLC | Yes | |
HLC | Yes | |
WDR | 120 dB | |
Scene Self-adaptation (SSA) | Yes | |
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | |
Gain Control | Auto;Manual | |
Noise Reduction | 3D NR | |
Motion Detection | OFF/ON (4 areas, rectangular) | |
Region of Interest (RoI) | Yes (4 areas) | |
Image Stabilization | Electronic Image Stabilization (EIS) | |
Smart Illumination | Yes | |
Defog | Yes | |
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) | |
Mirror | Yes | |
Privacy Masking | 4 areas | |
Audio | ||
Built-in MIC | Yes | |
Audio Compression | PCM; G.711A; G.711Mu; G.726; G.723 | |
Alarm | ||
Alarm Event | No SD card; SD card full; SD card error; | |
SD card durability warning; network disconnection; IP conflict; illegal access; security exception; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; video metedata; people counting in area; people counting; queue management | ||
Network | ||
Network Port | RJ-45 (10/100/1000 Base-T) | |
SDK and API | Yes | |
Cyber Security | Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade | |
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP | |
Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P | |
User/Host | 20 (Total bandwidth: 80 M) | |
Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS | |
Browser | With plug-in: | |
IE: IE 8 and later | ||
Chrome: 45 and earlier | ||
Firefox: 46 and earlier | ||
Safari: 12 and earlier | ||
Without plug-in: | ||
Edge | ||
Chrome: 45 and later | ||
Firefox: 46 and later | ||
Safari: 12 and later | ||
Management Software | Smart PSS; DSS; DMSS | |
Mobile Client | iOS; Android | |
Certification | ||
Certifications | CE-LVD: EN62368-1; | |
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; | ||
FCC: 47 CFR FCC Part 15, Subpart B; | ||
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14; | ||
UL 50E NEMA Type 4X (optional) | ||
Port | ||
RS-485 | 1 (baud rate range:1200 bps–115200 bps) | |
Audio Input | 1 channel (RCA port) | |
Audio Output | 1 channel (RCA port) | |
Alarm Input | 3 channels in: 5 mA 3 V–5 VDC | |
Alarm Output | 2 channels out: 1,000 mA 30 VDC/500 mA 50 VDC | |
Power | ||
Operating Conditions | –40°C to +65°C (–40°F to +149°F)/Less than 95% RH | |
Storage conditions | –40°C to +65°C (–40°F to +149°F) | |
Protection Grade | IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional) | |
Environment | ||
Operating Temperature | –30 °C to +65°C (–22 °F to +149 °F) | |
Operating Humidity | ≤95% | |
Structure | ||
Casing | Metal + plastic | |
Product Dimensions | 340.1 mm × 108.5 mm × 92.9 mm (13.39" × 4.27" ×3.66") (L × W × H) | |
Net Weight | 1.58 kg (3.48 lb) | |
Gross Weight | 2.48 kg (5.47 lb) | |
