  • 4MP Lite IR Fixed focal Bullet IP Network Camera IPC HFW2431S S S2 Waterproof Camera with POE
4MP Lite IR Fixed focal Bullet IP Network Camera IPC HFW2431S S S2 Waterproof Camera with POE
4MP Lite IR Fixed-focal Bullet IP Network Camera IPC-HFW2431S-S-S2 Waterproof Camera with POE

4MP Lite IR Fixed focal Bullet IP Network Camera IPC HFW2431S S S2 Waterproof Camera with POE

Share on (1600863346643):


Price:$48.00 - $50.00

Quantity:


Product Overview

Description



4MP Lite IR Fixed-focal Bullet IP Network Camera IPC-HFW2431S-S-S2 Waterproof Camera with POE


Products Description


4MP Lite IR Fixed-focal Bullet Network Camera
> 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
> Outputs 4MP (2560 × 1440)@25/30fps, Max. supports 4MP (2688 × 1520)@20 fps
> H.265 codec, high compression ration, ultra-low bit rate
> Built-in IR LED, max IR distance: 30 m
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP
conflict, illegal access, voltage detection
> Supports max. 256 GB Micro SD card
> 12V DC/PoE power supply
> IP67 protection


Product Paramenters


Camera
Image Sensor
1/3” 4Megapixel progressive CMOS
Max. Resolution
2688 (H) × 1520 (V)
ROM
128 MB
RAM
128 MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–1/100000 s
S/N Ratio
> 56 dB
Min. Illumination
0.008 Lux@F1.6
Illumination Distance
30 m (98.43 ft)
Illuminator On/Off Control
Auto/Manual
Illuminator Number
1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type
Fixed-focal
Mount Type
M12
Focal Length
2.8 mm
3.6 mm
Max. Aperture
F1.6
F1.6
Field of View
2.8 mm:
Horizontal:102.0° × Vertical 55.0° × Diagonal 121.0°
3.6 mm :
Horizontal 84.0° × Vertical 45.0° × Diagonal 100.0°
Iris Type
Fixed
Close Focus Distance
2.8 mm: 0.9 m (2.95 ft)
3.6 mm: 1.6 m (3.61 ft)
DORI Distance
Lens
2.8 mm
3.6 mm
Smart event
IVS
Tripwire; intrusion
Video
Video Compression
H.265; H.264; H.264B; MJPEG(only supported
by sub stream)
Smart Codec
Smart H.265+/ Smart H.264+
Video Frame Rate
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)
Stream Capability
2 streams
Resolution
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p
(1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night
Auto(ICR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
120 dB
White Balance
Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control
Auto/Manual
Noise Reduction
3D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest(RoI)
Yes (4 areas)
Smart Illumination
Yes
Image Rotation
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)
Mirror
Yes
Privacy Masking
4 areas
Alarm
Alarm Event
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering;
tripwire; intrusion; voltage detection; security exception
Network
Network
RJ-45 (10/100 Base-T)
SDK and API
Yes
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering;
generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP;
IGMP; NFS; PPPoE; 802.1x; Bonjour
Interoperability
ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec
User/Host
20
Storage
FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser
IE
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Phone
IOS; Android
Certification
Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Power
Power Supply
12V DC/PoE (802.3af)
Power Consumption
< 5W
Environment
Operating Conditions
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95% RH
Strorage Conditions
-40°C to +60°C (-40°F to +140°F)
Protection
IP67
Structure
Casing
Metal
Dimensions
166.2 mm × Φ70 mm (6.54" × Φ2.76")
Net Weight
0.48 kg (1.1 lb)
Gross Weight
0.57 kg (1.3 lb)


Company Profile





\tBejing Sinlay technology limited is a young ,creative and energetic company located in beijing.with a strong focus on service and providing innovative,high quality and competitively priced products including Hikvision/dahua CCTV Camera,IP Video solutions and so on.

Our products are sold far to Europe, America, Southeast Asia and other countries and regions. High quality, good price, on time delivery and sincere service are our value and promises to our customers. As an enterprise integrating manufacture and sales, we have confidence to launch more competitive products to cope with severe competition. Sinlay is your sincere partner!




FAQ


01

How to confirm whether the product is Dahua and Hikvision genuine English version?

You can download software in the official website of Dahua and Hik vision,only Dahua and Hik vision genuine product is compatible with the software.And we promise all of our products are Dahua and Hik vision genuine products.



02

When will you ship my order？

Ordinary,once we get confirmation for payment,we will ship order within 1-2 days.



03

Can I install the IP camera by myself?

Of course,the camera is flexible installated.And there is a user manual within box,you can contact us in need.



04

How is your after-sale service?

Three engineers work more than five years we will respond your technical support within 24 hours.



05

Do you support drop shipping?

Yes,your drop shipping is aviable.



06

How about warranty?

Two years warranty.
