Product Overview

Description







Cummins brand diesel engines can be customized


Model
MS450-10 Ⅱ
MS400-13 Ⅱ
MS500-13 Ⅱ
Cummins engine
Cummins 110kw
Cummins 110kw
Cummins 132kw
Diesel tank volume
135L
135L
230L
Rated F.A.D
12 m3/min
11m3/min   388 cfm
15 m3/min
Rated Pressure
10 bar
13 bar
13 bar
Weight
2450 kg
2450 kg
2700 kg
Dimensions(LxWxH)
3220*1850*1850 mm
3220*1850*1850 mm
4200*1980*2210 mm


Contact Us



24 hours for you




Cummins Diesel Compressor


Cummins brand diesel engines can be customized


CS Series Cummins Mobile Air Compressors
Model
Click On
Rated F.A.D
Rated Pressure
Cummins
Engine
Diesel tank
Weight
kg
Dimensions
(LxWxH) mm
CS212- 8
8.0m3/min  282cfm
8 bar
60kw
85L
1300
2700×1600×1700
CS353-10
10.0 m3/min 353cfm
10 bar
60kw
100L
2350
3000x1610x2350
CS500-12
14.0 m3/min 494cfm
12 bar
103kw
135L
2490
3000×1610×2350
CS500-14
14.0m3/min 494cfm
14 bar
132kw
230L
2550
3250×1610×2470
CS530-15Z
15.0m3/min 530cfm
15 bar
140kw
230L
2500
3250×1610×2470
CS565-16
16.0m3/min 565cfm
16 bar
153kw
230L
3250
3345×1750×2460
CS636-17
18.0m3/min 636cfm
17 bar
194kw
230L
3750
390×1910×2520
CS777-24
22.0m3/min 777cfm
24 bar
264kw
230L
4300
3950×2000×2550
CS1000-25
30.0m3/min 1060cfm
25 bar
338kw
345L
4550
3950×200×2550
CS1300-30
36.0m3/min 1272cfm
30 bar
410kw
345L
5500
4220×200×2300
MS Series Cummins Mobile Air Compressors





Model
Click On
Rated F.A.D
Rated Pressure
Cummins
Engine
Diesel tank
Weight
kg
Dimensions
(LxWxH) mm
MS330-  8 Ⅲ
10.0m3/min 353cfm
8 bar
92kw
100L
1950
2880*1740*1760
MS300-10 Ⅲ
8.50m3/min 300cfm
10 bar
92kw
100L
1950
2880*1740*1760
MS460-  8 Ⅱ
13.0m3/min 459cfm
8 bar
110kw
135L
2450
3220*1850*1850
MS450-10 Ⅱ
12.0m3/min 424cfm
10 bar
110kw
135L
2450
3220*1850*1850
MS400-13 Ⅱ
11.0m3/min 388cfm
13 bar
110kw
135L
2450
3220*1850*1850
MS500-13 Ⅱ
15.0m3/min 530cfm
13 bar
132kw
230L
2700
4200*1980*2210
MS500-16 Ⅲ
15.0m3/min 530cfm
16 bar
132kw
230L
2700
4200*1980*2210
MS700-18 Ⅱ
18.0m3/min 636cfm
18 bar
164kw
230L
4500
3980*1980*2320
MS800-20 Ⅱ
22.0m3/min 777cfm
20 bar
194kw
230L
5300
4080*2080*2100


Chinese Diesel Engine Compressor


Model
CLICK ON
Rated F.A.D
Rated Pressure
China III Engine
Diesel tank
Weight
kg
Dimensions
(LxWxH) mm
SD 40CKY-8
5.0m3/min
8 bar
Xichai/36.8kw
50L
730
1,670×990×1,550
SD 40SCY-7
4.5m3/min
7 bar
Xichai/36.8kw
65L
860
2,400×1,330×1,550
SD 40SCG-7
4.5m3/min
7 bar
Xichai/36.8kw
65L
750
1,800×1,040×1,300
SD 60SCY-7
9.0m3/min
7 bar
Xichai/59kw
85L
1,280
2,700×1,600×1,700
SD 110SCY-10
12.5m3/min
10 bar
Xichai/118kw
135L
2,350
3,000×1,610×2,350
SD 141SCY-15
15.0m3/min
15 bar
Xichai/140kw
230L
2,500
3,250×1,610×2,470
SD 141SCY-15B
15.0m3/min
15 bar
Cummins/140kw
230L
2,500
3,250×1,610×2,470
SD 110SCYT-18
12.0m3/min
18 bar
Yuchai/118kw
230L
2,350
3,800×2,100×2,300
SD 145SCYT-12-18
17-15m3/min
12/18 bar
Yuchai/140kw
230L
2,900
4,350×2,200×2,370
SD 162SCYT-18
17.0m3/min
18 bar
Yuchai/162kw
230L
3,250
3,345×1,750×2,460
SD 186SCYT-18
19.0m3/min
18 bar
Yuchai/191kw
345L
3,700
3,900×1,910×2,520
SD 198SCYT-20
20.0m3/min
20 bar
Yuchai/191kw
345L
3,750
3,900×1,910×2,520
SD 220SCYT-22
22.0m3/min
22 bar
Yuchai/221kw
345L
3,900
3,900×1,910×2,560
SD 298SCYT-24
29.0m3/min
24 bar
Yuchai/295kw
485L
4,800
4,180×2,080×2,995
SD ZCY550-15B
15.0m3/min
15 bar
Cummins/132kw
230L
2,500
3,250×1,610×2,470
SD ZCY700-18
20.0m3/min
18 bar
Cummins/194kw
345L
3,700
3,900×1,910×2,520
SD S60T
18.0m3/min
18 bar
Yuchai/162kw
230L
3,050
3,220×1,670×2,150
SD S85T
24.0m3/min
22 bar
Yuchai/228kw
350L
3,450
3,560×1,830×2,100
SD S95T
29.0m3/min
24 bar
Yuchai/295kw
415L
4,300
3,950×2,000×2,550
SD S100T
31.0m3/min
25 bar
Yuchai/309kw
415L
4,550
3,950×2,000×2,550
SD S125D
36.0m3/min
30 bar
Yuchai/410kw
600L
5,500
4,220×2,000×2,300
