R410A Dc Inverter Swimming Pool Heat pumps Manufacture For Swimming Pool Heating
- Category: >>>
- Supplier: Foshan Blueway Electric Appliances Co. Ltd.
Share on (1600864675635):
Product Overview
Description
Pool Heat Pump Industrial Water Chiller Price High Quality Industrial Water Cooled Chiller Using Swim Pool Heat Pump
Product Category
Product Description
Pool Heat Pump Industrial Water Chiller Price High Quality Industrial Water Cooled Chiller Using Swim Pool Heat Pump
Product details
| Brand name | Blueway |
| Color | Grey or White |
| COP | 4.0~4.5 |
| Fan discharging | Vertical or Horizontal |
| Material | Galvanized Steel Powder Coated/Plastic/Stainless steel |
| Max/Rated temperature | 28℃/40℃ |
| Place of origin | Guangdong China |
| Products type | Swim Pool heat pump |
| Refrigerant | R410A |
| Application | Home,Villa,SPA, School, Hotels, Hospital |
| Product Keywords | swim pool heat pump,chiller water cooled,industrial water chiller |
Blueway R32 Inverter swimming pool heat pump is a smart and reliable solution to heat the pool and spa. With most of the energy absorbed from the air, pool heat pumps can heat the pool and spa all year round with much less cost. Running at low cost and without CO2 discharging, people can enjoy swimming or spa at pleasant water temperature all over the year.
| Model | SPCH-I-2.0S | SPCH-I-3.0S | SPCH-I-4.0S | SPCH-I-5.0S | SPCH-I-6.0S | SPCH-I-5S | SPCH-I-6S | SPCH-I-7S | SPCH-I-10S | SPCH-I-15S | SPCH-I-25T | |||
| HP | 2 | 3 | 4 | 5 | 6 | 5 | 6 | 7 | 10 | 15 | 25 | |||
| Power Supply | V/Hz/Ph | 220-240/50/1, 208-230/60/1 | 380-415/50/3, 208-230/60/3, 380-415/60/3 | |||||||||||
| Heating performance | Heating (1): A26/19°C W26/28°C | Heating capacity | kW/h | 2.5~9 | 3.0~12 | 4.0~17 | 5.0~20 | 6.0~24 | 5.0~20 | 6.0~24 | 7~28 | 9~38.5 | 12~59 | 24~116 |
| Power consumption | kW | 0.2~1.65 | 0.24~2.22 | 0.33~3.2 | 0.42~4.15 | 0.51~5 | 0.42~4.1 | 0.5~4.95 | 0.58~5.5 | 0.75~8 | 1~12 | 2~23 | ||
| COP | w/w | 12.5~5.45 | 12.5~5.4 | 12.1~5.31 | 11.9~4.82 | 11.76~4.8 | 12~4.9 | 11.9~4.86 | 12.1~5.1 | 12~4.81 | 12~4.92 | 12~5.04 | ||
| Heating (2): A15/12°C W26/28°C | Heating capacity | kW/h | 1.8~7.5 | 2.2~9.5 | 3~12.5 | 4~15.5 | 5~20 | 4~15.5 | 5~20 | 6~23.5 | 8~31 | 10~48 | 20~93.5 | |
| Power consumption | kW | 0.27~1.7 | 0.33~2.1 | 0.48~3 | 0.66~4 | 0.81~4.94 | 0.65~3.92 | 0.81~5 | 0.95~5.75 | 1.31~7.9 | 1.65~12.5 | 3.4~24 | ||
| COP | w/w | 6.7~4.4 | 6.67~4.52 | 6.25~4.17 | 6.06~3.88 | 6.17~4.05 | 6.15~3.95 | 6.2~4 | 6.32~4.1 | 6.11~3.92 | 6.06~3.84 | 5.88~3.9 | ||
| Cooling performance | Cooling: A35/24°C W30/28°C | Cooling capacity | kW/h | 2~5.5 | 3~7.5 | 5~10.5 | 7~12.5 | 7.5~14 | 7~12.5 | 7.5~14 | 8~17 | 15~25 | 18~38 | 36~72 |
| Power consumption | kW | 0.42~1.7 | 0.61~2.25 | 1~3.2 | 1.37~3.85 | 1.4~4.23 | 1.35~3.9 | 1.37~4.3 | 1.4~5 | 2.7~7.35 | 3.2~11.2 | 6.55~21.5 | ||
| EER | w/w | 4.76~3.24 | 4.92~3.33 | 5~3.28 | 5.1~3.25 | 5.36~3.31 | 5.19~3.2 | 5.47~3.25 | 5.7~3.4 | 5.56~3.5 | 5.63~3.39 | 5.5~3.35 | ||
| Ambient temp. range | °C | -7~46 | ||||||||||||
| Rated/Max.outlet water temp. | °C | 28/40 | ||||||||||||
| Rated water flow rate | m³/h | 3.8 | 5.2 | 7.3 | 8.6 | 10.3 | 8.6 | 10.3 | 12 | 16.6 | 25.4 | 50 | ||
| Rated pressure drop | kPa | 4 | 5 | 5 | 7 | 13 | 7 | 13 | 15 | 15 | 17 | 23 | ||
| Controller | - | Micro processor based digital wire controller with LCD display | ||||||||||||
| External cabinet | - | Galvanized steel with powder coating | ||||||||||||
| Compressor | Type | - | Rotaty | Scroll | ||||||||||
| Qty. | Nos. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | ||
| Refrigerant | - | R32/R410a | ||||||||||||
| Water heat exchanger | - | Titanium tube in PVC shell | ||||||||||||
| Water connection | Inlet&Outlet | inch | DN40 | DN40 | DN40 | DN40 | DN50 | DN40 | DN50 | DN50 | DN65 | DN65 | DN80 | |
| Sound pressure at 1m | dB(A) | 40~51 | 42~52 | 44~53 | 45~56 | 46~58 | 45~56 | 46~58 | 45~59 | 48~62 | 49~63 | 62~72 | ||
| Air discharge | - | Side discharge | Top discharge | |||||||||||
| Net dimension | W*D*H | mm | 950*380*610 | 950*380*610 | 1110*430*700 | 1100*430*800 | 1100*430*960 | 1100*430*800 | 1100*430*960 | 1050*400*1260 | 1100*480*1480 | 1400*525*1630 | 2000*950*2100 | |
| Net weight | kg | 43 | 45 | 54 | 70 | 90 | 70 | 90 | 105 | 210 | 235 | 600 | ||
