Total Length | 12'6" |
Total Width | 6'4" |
Height (RTT Not Included) | 5'9" |
Tongue Box | 47 1/2" W x 22 3/8" L x 29" H |
Gear Box | 47 1/2" W x 28 1/2" L x 32" H |
Rack Size | 47 1/2 " W x 72" L x 7" H |
Rack Load Weight | 500 lbs |
Water Heater (EccoTemp L5 37,500 BTU) | YES |
Single Battery (Group 27 DC 90 Amp Hours | YES |
Dual Batteries (Group 27 DC 90 Amp Hours) | YES |
Hitch/Coupler (2" Ball, 1 7/8" Ball, Max Coupler) | 2 " or Max Coupler |
Stove (Partner Steele Dual Burner 10,000 BTU) | 22" (Modified) |
Tire Size | 285/70/R17 |
Wheel Size | 17x9 |
Wheel Bolt Pattern | 5x5 (Can Be Changed) |
Water Tank Size | 17 Galllon |
Propane Tank Size | 11lb |
Spare Tire Swing | YES |
Jerry Can Box | NO |
Suspension | 3500 lb. Timbren Axle-less |
Brakes | 10" Drum |
Galley | NO |
Sleeping Arrangements | Roof Top Tent |
Fridge Accomodations | 47" W x 22" L x 21" H |
Fridge Accomodations | Not Included |
Ground Clearance | 25 x/8" (Frame), 22 7/8" (Tank) |
Frame | Steele |
Solar Capable | YES |
Trailer Connection Type | 7 - Way |
Dry Weight | 1350 lbs. |
Maximum GVWR | 3500 lbs. |
Tongue Weight (Dry & Unloaded) | 75 lbs. |
Available Custom Colors | YES (Contact Us) |
Supports Awning | YES (Not Included) |
