Low Price Good Performance Used Bauxite Rotary Sintering Kiln Machine Equipment Hot Sale In Thailand
- Category: >>>
- Supplier: Henan Yuhong Heavy Machinery Co. Ltd.
Share on (1600865848182):
Product Overview
Description
BRIEF INTRODUCTION
Rotary kiln is the key equipment for the calcination of bauxite, clinker, limestone, etc.. According to the capacity of bauxite plant, clinker or cement plant, etc..
APPLICABLE MATERIALS
The rotary kiln can process the lime, cement, coal mangue, bauxite, mudstone, Iron ore, lead and zinc ore, silver and manganese ore, molybdenum and rhenium ore, other metallic ores and non-metallic ores. etc.
PRODUCT PARAMETERS
Model | Rotate speed | Inclination | Capacity | Power | Weight |
(r/min) | (%) | (t/d) | (kw) | (t) | |
Φ1.4×33 | 0.39~3.96 | 3 | 25 | 18.5 | 47.5 |
Φ1.6×36 | 0.26~2.63 | 4 | 40 | 22 | 52 |
Φ1.8×45 | 0.16~1.62 | 4 | 70 | 30 | 78.2 |
Φ1.9×39 | 0.29~2.93 | 4 | 75 | 30 | 77.59 |
Φ2.0×40 | 0.23~2.26 | 3 | 100 | 37 | 119.1 |
Φ2.2×45 | 0.21~2.44 | 3.5 | 150 | 45 | 128.3 |
Φ2.5×40 | 0.44~2.44 | 3.5 | 250 | 55 | 149.61 |
Φ2.5×54 | 0.48~1.45 | 3.5 | 300 | 55 | 196.29 |
Φ2.7×42 | 0.10~1.52 | 3.5 | 400 | 55 | 198.5 |
Φ2.8×44 | 0.437~2.18 | 3.5 | 600 | 55 | 201.58 |
Φ3.0×48 | 0.6~3.48 | 3.5 | 800 | 100 | 237 |
Φ3.2×50 | 0.674~3.37 | 3.5 | 1000 | 160 | 252.4 |
Φ3.5×52.5 | 0.6~3.6 | 3.5 | 1500 | 180 | 366.5 |
Φ4.0×60 | 0.396~3.96 | 3.5 | 2500 | 315 | 523 |
Φ4.3×64 | 0.4~3.96 | 3.5 | 3200 | 420 | 606.69 |
Φ4.8×72 | 0.39~3.96 | 3.5 | 5000 | 630 | 853.3 |
Φ5.2×61 | 0.38~3.79 | 3.5 | 5500 | 800 | 859 |
Φ5.0×80 | Max.3.5 | 4 | 6000 | 800 | 1201 |
Φ5.6×87 | Max.4.23 | 4 | 8000 | 800 | 1227.5 |
PRODUCTION LINE
The Rotary kiln is mainly composed of kiln shell, refractory bricks, supporting device, supporting device with catch wheel, transmission device, lubrication device, mobile kiln head and sealing device at the end of the kiln.
1. Supporting device: advanced shaft structure, automatic temperature measuring device and electrical heating.
2. Catch wheel: including two kinds mechanical wheel and hydraulic pressure.
3. Gears: single or double. Control the rotating speed by buncher, DE machine and frequency variable motor. Be reliable, energy-saving, and efficient.
4. Kiln shell tire bolster: lower bolster has three types: fixed, zoom and floating. The structure is simple, replacement is convenient and won’t hurt cylinder.
5. Sealing equipment: there are many kinds for choice according to kiln models, including air cylinder edge sealing, spring edge sealing, and graphite block sealing and combination for above. The sealing effect is very good.
6. Kiln head hood: including stationary type and flexible type.
FAQ
Q1: Why choose YuHong machinery?
A1: 1. Up-to-date design, CAD calculation and simulation;
2. ISO,BV,SGS,CE quapty control manufacturing;
3. Over 30 years experience, export to over 50 countries;
4. Highest standard to suit operators' use;
5. World class quality at affordable price.
Remarks: The price will depend on different models. Reply message ,you will get 5% discount price.
CONTACT SUPPLIER
Q2: What are the requirements for rotary kiln material?
A2: Our Yuhong has a high standard on choosing material of rotary kiln.
1.Using very high grade steel plate (i.e. Q235, Q345) on structuring part;
2. Using wear-resistant steel (i.e. ZG35, ZGMn13, 65Mn, 35CrMo, ZG60Si2CrA) on quick-wear parts;
3. The motor, reducer, bearing, belt, bolts are Chinese top 5 brands;
4. Metallurgy performance must be considered during designing, cutting, bending, fitting&welding.
CONTACT SUPPLIER
Q3: What information do we need to provide you the reasonable model and best quotation?
A3: 1. What is the raw material?
2. What is the heating fuel?
4. What is the capacity per hour?
CONTACT SUPPLIER
HENAN YUHONG HEAVY MACHINERY CO., LTD.
Henan Yuhong Heavy Machinery Co.,LTD is a joint-stock mining machinery manufacturing enterprise integrated in scientific research,prodcution and marketing.our main products include five series ,they are the Crushing equipment ,Beneficiation equipment,Grinding Powder equipment ,Drying equipment ,Kilning equipment.YUHONG GROUP set off from "the customer for this " angle ,put self's whole heart to be that the customer provides the valuable service pattern,the effort using up 100% satisfies different customer product need.
