Airstone 2.2kW 3HP Oil Free Scroll Air Compressor For Automotive Paint Spraying

Product Overview

Description

Airstone 2.2kW 3HP Oil Free Scroll Air Compressor For Automotive Paint Spraying

Oil free scroll air compressor priciple:

The orbiting scroll rotates in the order of 1-2-3-4 as shown in the diagram,  the air is sucked into the space between the orbiting scroll and the stationary scroll, the volume of the crescent compression chamber gradually decreases, and then the air is discharged from the exhaust port at the center of the stataionary scroll after being compressed.

High-precision processing technology is required to produce the components that make up a Scroll Oil Free Air Compressor.

Fetures of oil free scroll air compressor:

-Low specific power, High energy efficiency.

-Long term warranty , and low maintenance.

-Small footprint & extremely quite operation.

-Noise of the complete system equipped with 3.7kw scroll oil free compressor is under 59dB.

-Low vibration,  under standard working conditions, the vibraion of main unit is less than 7.1mm/s.



Model Number	AS-XP2.2F	AS-XP3.7F	AS-XP5.5A	AS-XP7.4C	AS-XP11A	AS-XP16.5A	AS-XP22A	AS-XP33B	AS-XP44A
Power(kW)	2.2	3.7	5.5	7.4	11	16.5	22	33	44
Airend Qty	2.2*1	3.7*1	5.5*1	3.7*2	5.5*2	5.5*3	5.5*4	5.5*6	5.5*8
Capacity(m3/min)	0.24	0.4	0.6	0.8	1.2	1.8	2.4	3.6	4.8
Pressure(bar)	8-10	8-10	8-10	8-10	8-10	8-10	8-10	8-10	8-10
Voltage	380V/50Hz/3PH
Control Method	PLC touch screen control
Motor	IP55
Connector Size	G1/2"				G3/4"	G1 1/2"

The oil free scroll air compressor applications include food and beverage processing, the pharmaceutical industry (manufacturing and packaging), waste water treatment, chemical and petrochemical processing, semiconductor and electronics manufacturing, the medical sector, automotive paint spraying, textile manufacturing and many more.
Contamination by even the smallest quantities of oil can result in costly production downtime and product spoilage, making class 0 an industry standard.

Q1. What is an oil free scroll air compressor?
A:Oil-free scroll compressors prevent oil from entering your compressed air system, guaranteeing consistently pure, oil-free air that's required by many manufacturing applications. Oil lubrication is not required in scroll compressors since there is no metal to metal contact, making the compressor entirely oil free.

Q2. What is the maximum pressure for a oil-free scroll compressor?
A: 100 to 150 psi (8-10bar)
Nonetheless, scroll compressors can typically generate relatively high pressures — 100 to 150 psi — in single-stage units. Forengineers, scroll compressors can offer a number of benefits.

Q3. What is the difference between oil free scroll air compressor and oil free rotary compressor?
A: Scroll and rotary screw compressors mainly differ in their duty cycle capacity. While scroll compressors can easily change power cycles, rotary screw compressors struggle to adapt in medium-to-low volume cycles.
