UL1371 FEP Insulated Stranded Tinned Copper Wire Heat Resistant Electrical Cable for Home Appliances and Electronics

Product Overview

Description

1) Product: FEP wire
2) Style No.: AWM1371
3) Size: 36AWG ~ 10 AWG
4) Rated Voltage: no requirement
5) Rated Temperature:-65°C~+105°C
6) Conductor: tinned copper
7) Insulation: FEP

8) Color: red / yellow / blue / white / black / yellow green / brown / orange / purple / green / etc.



Product features
Has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance, high voltage resistance, aging resistance, long service life and soft and easy to install.

Applications
* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.



AWG	Conductor construction NO.×mm	Insulation Thickness mm	Outer Diameter mm	m/coil
10	37×0.43	0.33	3.67	305
12	19×0.49	0.33	3.11	305
14	19×0.37	0.33	2.51	305
16	19×0.30	0.14	1.90	305
17	19×0.26	0.14	1.70	305
18	19×0.23	0.14	1.55	305
20	19×0.18	0.14	1.23	305
20	1×0.80	0.14	1.08	305
22	19×0.16	0.14	1.08	610
22	1×0.65	0.14	0.93	610
24	7×0.20	0.14	0.88	610
24	1×0.50	0.14	0.78	610
26	7×0.16	0.14	0.76	610
26	1×0.40	0.14	0.68	610
28	7×0.12	0.14	0.64	610
28	1×0.32	0.14	0.60	610
30	7×0.10	0.14	0.58	610
30	1×0.254	0.14	0.534	610
32	7×0.08	0.14	0.52	610
32	1×0.20	0.14	0.48	610
34	7×0.06	0.14	0.46	610
34	1×0.16	0.14	0.44	610
36	7×0.05	0.14	0.43	610
36	1×0.12	0.14	0.40	610
